Specifications
Kilowatt | 3 kW |
Length (L.1) | 339 mm |
Mount Hole Center - Center (O.1) | 127 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 47 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | NIKKO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HOUGH | Various Models | 01.1989- | |
KOMATSU | Various Models | 01.1988- |
Reference Information
112668 20409541BN UD100821(NIKKO)S STR80071 0-23000-2070 140-28148 CST60145AS 10461483 MAV621450A 10461287 540.507.103.038 1113284 6060145 0-61000-0280 540.507.103.030 91-01-4414 STD2668 91-01-4414NAdd Your Number
