Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 186 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_9104 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley to Mount Distance (A) | 27 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Grand Voyager 2.5 TD | [425CLIRS/X] | 01.1995-03.2001 |
| CHRYSLER | Grand Voyager 2.5 TD | [ENC] | 01.1995-03.2001 |
| CHRYSLER | Grand Voyager 2.5 TDiC AWD | [ENC] | 10.1995-03.2001 |
| CHRYSLER | Voyager 2.5 TD | [425CLIRS/X] | 01.1995-03.2001 |
| CHRYSLER | Voyager 2.5 TD | [ENC] | 01.1995-03.2001 |
| CHRYSLER | Voyager 2.5 TDiC AWD | [ENC] | 10.1995-03.2001 |
| DODGE | Caravan 2.5 TD | [ENC] | 01.1995-03.2001 |
Reference Information
89212575 20101282RC ALTS794 DZ1310 LRA01821 CAL10282RS 209067 441625 EAA-211159 38522303 4727206 9.44391E+11 DRZ0200 28-3645 LRA1821 ALT122820 2010282.1 BOS0123510037 2010282.2 123510037 385221288F KRL014342AB 4041 BOM UNIT ALB1478 20101282OE 038522288F 835.501.115 CAL10282GS 56721 0123510037 310843 ALT1562 05014342AB 220-335 38522288F CA1478IR MRA90136Add Your Number
