Specifications
| Amp | 75 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Grooves | 2 qty |
| Length (L.1) | 227 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MITSUBISHI | L 400 2.5 TD 2500 | [4D56T] | 06.1996- |
| MITSUBISHI | L 400 2.5 TD 2500 | [4D56T] | 09.1996- |
| MITSUBISHI | L 400 2.5 TD 2500 4WD | [4D56T] | 09.1996- |
| MITSUBISHI | Space Gear 2.5 TD | [4D56TD] | 05.1995-05.2000 |
| MITSUBISHI | Space Gear 2.5 TD 4WD | [4D56TD] | 05.1995- |
Reference Information
20137101BN A2TN1199AM 112128 89212236 155.604.075.130 A2TN1199AT MRA42291 A003T82899 DA4584 2035101 20137101OE 155.604.065.130 JA1271IR A003T15099 155.604.065.370 DRA3474N CAL35101AS 8EL011711-091 MD313940 155.604.075.780 A002TN1199AM A002T82899AM A003TN0299 A002TN1199 MD313942 A002TN1199AT ANM36446 A3TN0399 DRA3474 A3TN0999 0986045571 2035101.1 600054 A003TN0499 155.604.065.360 PRAL702 A2T82899 AG0400 437706 A2T82899AM A002TN1199A ALM1271 A3T15099 CAL35101GS MD315432 A2T1199AT ALT31078 DA5336 401271RIV A002T1199AT 63731271010 LRB236 401271RI A12MH1144A2 9.4439E+11 A3T82899 0986042291 311788 A2T82899A A2TN1199 A002TN1199ZT 986045571 56718 DA4584N A2TN1199A A002T82899A ALTL702 MD306649 EAA-222120 A003TN0399 155.604.075.360 LRB00236 8EL737375-001 MD366051 A3TN0299 9372 MD306834 MD332547 A3TN0499 A2TN1199ZT DRA4226 MD327514 MD366050 28-2844 A002T82899 J5110501 RAA14585 986042291 MQA1271 A003TN0999 210018 401271RILAdd Your Number
