Specifications
| Amp | 105 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 44 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 70 mm |
| Pad mount thickness (E.1) | 46 mm |
| Pad mount thickness (E.2) | 46 mm |
| Pad mount thickness (E.3) | 46 mm |
| Pad mount thickness (E.4) | 15 mm |
| Plug Code | PL_4001 |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Pulley to Mount Distance (A) | 35.6 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Accord 2.0 i | [R20A3] | 07.2008- |
| HONDA | Accord 2.2 DTDi | [N22A1] | 01.2004-06.2008 |
| HONDA | Accord 2.2 i-CTDi | [N22A1] | 02.2004- |
| HONDA | Accord 2.2 i-DTEC | [N22B1] | 07.2008- |
| HONDA | Accord 2.4 i | [K24Z3] | 07.2008- |
| HONDA | Civic 2.2 CTDi | [N22A2] | 01.2006- |
| HONDA | CR-V 2.2 CTDi | [N22A2] | 03.2005-09.2006 |
| HONDA | CR-V 2.2 i CTDi | [N22A2] | 01.2007- |
| HONDA | FR-V 2.2 i CTDi | [N22A1] | 07.2005- |
Reference Information
0986082050 ALT30361R CSD89 CSD86 RNL1042103911IN 89212239 ALT30361 125.531.105.208 301980RID 104210-3910 104210-3911 31100-RBD-E01 021080-1010 ANM32373X ALTJ026 301980RI 31100-RBD-E02 CAL40239AS CA1980IR 23971R 2H431 125.531.105.050 J5114048 20132932BN AG1224 ALN1980 DAN985 DAN984 23971N 20132932OE 8EL012430-661 LRA2971 DA1263 446668 A12DE0067 986082050 125.531.105.263 ALT6192 63731980010 LRA02971 NEK2971 RNL104210-3911 2040239 57161 114208 ALH431 63377522010 CSC914E 002-H431 ALT6228 104210-4860 RAA11264 210844 28-5585 AEK2971 9379 125.531.105.059 125.531.105.058 125.531.105.417 63377523010 CAL40239GS DRA0153 021080-0010 A12DE0067A2 EAA-221260 2040239.1 31100-RSR-E01 SB306 CSC91 125.531.105.260 ALT709CP PRAJ026Add Your Number
