Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 171 mm |
Mount Inside Length or Pad Mount C-C (C) | 51.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Remanufactured |
Pulley to Mount Distance (A) | 34 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.6 | [1ZR-FE] | 03.2007-09.2012 |
TOYOTA | Corolla 1.6 | [1ZR-FAE] | 11.2006-11.2013 |
TOYOTA | Corolla 1.6 | [1ZR-FE] | 11.2006-11.2013 |
TOYOTA | Corolla 1.6 Dual VVTi | [1ZR-FE] | 01.2007-07.2014 |
Reference Information
4271 554664RID 63377565010 LRA3356 ALN6110 2040367.1 28-5968 MAN7565 AEC2027 ALT423670 89215773 195.937.090.260 PRAF398 447081 27060-0T012 27060-0T011 27060-0T010 114455 LRA03356 209435 DA2014 8EL012240-691 20132763OE ALTF398 CAL40367GS 101210-0912 20487R DENDAN1061 101210-0910 101210-0911 ALT6151 DAN1061 DRA0904Add Your Number
