Specifications
| Amp | 110 A |
| Bottom Mounting Foot Width (B) | 16 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Diameter (D.4) | 10.5 mm |
| Grooves | 7 qty |
| Length (L.1) | 264 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 68 mm |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Remanufactured |
| Pulley to Mount Distance (A) | 43 mm |
| Pulley Type | CLUTCH |
| Unit Type | HYUNDAI / KIA |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | H-1 2.5 CRDi | 11.2002- | |
| HYUNDAI | H-1 2.5 CRDi Starex | 12.2002- | |
| HYUNDAI | H-1 2.5 CRDi Starex 4WD | 12.2002- | |
| KIA | Sorento 2.5 CRDi | [D4CB] | 08.2002- |
Reference Information
CAL32141GS 11.1804M 37300-4A110 37300-4A112 37300-4A111 20193511RE 37300-4A113 9.44391E+11 20193141OE LRA02791 ALT01035 2032115.4 255.604.110.369 255.604.110.009 255.604.110.008 2032115.1 373004A002 373004A003 255.604.110.000 2032115 JA1804IR 89213356 2032141.1 20193511BN AF111382 CAL32115OS 20193511OE 9090424 AEK2791 445931 ALT8713 11.1804 PRAL308 CAL32115GS 401804RIV A12HY0128A2 AF111393 ALTL308 SB353 401804RIM RNL1804JA 23791N ALT341150 600046 MRA90424 TA000A62401 210381 986080640 37300-4A000 37300-4A002 37300-4A001 37300-4A003 8EL738211-291 LRA2791 28-4908 DRA0075 401804RI A12HY0128 CAL32115AS ANM32295X 9407 0986080640 113792 155.609.110.415Add Your Number
