Specifications
Kilowatt | 2 kW |
Length (L.1) | 235 mm |
Mount Hole Center - Center (O.1) | 49 mm |
Mount Hole Center - Center (O.2) | 92 mm |
Mount Hole Center - Center (O.3) | 105 mm |
Mount Hole Diameter (C.1) | M12x1.75 mm |
Mount Hole Diameter (C.2) | M12x1.75 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 21 mm |
Rotation | CW |
Spigot Diameter (A) | 82.5 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | LT 28-35 2.5 TDi | [AHD] | 05.1996-05.1999 |
VW | LT 28-35 2.5 TDi | [ANJ] | 05.1999-07.2006 |
VW | LT 28-35 2.5 TDi | [APA] | 05.1999- |
VW | LT 28-35 2.5 TDi | [AVR] | 05.1999- |
VW | LT 28-35 2.5 TDi | [BBE] | 05.2001- |
VW | LT 28-35 2.5 TDi | [BBF] | 05.2001- |
VW | LT 40-55 2.5 TDi | [AHD] | 05.1996-05.1999 |
VW | LT 40-55 2.5 TDi | [ANJ] | 05.1999- |
VW | LT 40-55 2.5 TDi | [APA] | 05.1999-04.2001 |
VW | LT 40-55 2.5 TDi | [AVR] | 05.1999- |
VW | LT 40-55 2.5 TDi | [BBE] | 05.2001- |
VW | LT 40-55 2.5 TDi | [BBF] | 05.2001- |
Reference Information
000986018380 6010281.1 6010281.2 STM588 300.529.092.210 300.529.092.010 LRS01389 8EA737680-001 CST10281GS 25-2270 20513047 1516674R CGB-52270 069911023LX STR10178 MSRC1165 S12BH0785A2 101165 CST10281RS 300.529.092.280 986018380 9.4428E+11 MQS1165 CS1165 000B001126081 1125501 069911023E 1125502 MRS18380 069911023L PRSL231 331317 88212166 B001126081 MAV122810 3024 8EA012527-741 20401182OE 220581 ANM10600X 458495 42018380 0001125501 1125511 CST10281AS 1125512 0001125502 11886 20401182BN LRS1389 32389N STR50070 AEU1165 EAA-121128 6010281 9.43212E+11 300.529.092.212 63721165010 STRL231 300.529.092.018 112221 DRS8380 0001125511 0001125512 20401182RCAdd Your Number
