Associated Numbers
- ARROWHEAD ACR0004, ACR0005
- BOSCH AL502X
- CHRYSLER MOTORS 3438179, 3438180, 3438184
- DELCO 10463274, 10463278, 334-2212
- J&N ELECTRICAL PRODUCTS 400-10007
- LESTER 7019, 7021, 7509
Specifications
60A Version
* this alternator can be converted to a single wire alternator by using the regulator 230-10005
** Please note the Pivot Inside Length (C) measurement includes the spacer as per picture, The distance between the aluminium brackets is 60 mm**
Amp | 60 A |
Bottom Mounting Foot Width (B) | 12.5 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 10.5 mm |
Grooves | 2 qty |
Length (L.1) | 170 mm |
Mount Inside Length or Pad Mount C-C (C) | 7.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 45 mm |
Plug Code | PL_9102 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 30 mm |
Pulley Type | SOLID |
Unit Type | CHRYSLER |
Voltage | 12 V |
Reference Information
3438179, 3438180, 3438184
