Specifications
Amp | 175 A |
Diameter (D.1) | 10 mm |
Diameter (D.2) | 9 mm |
Diameter (D.3) | 9 mm |
Grooves | 5 qty |
Length (L.1) | 168 mm |
Mount Inside Length or Pad Mount C-C (C) | 90 mm |
Outside Diameter (O.D.1) | 55.5 mm |
Pad mount thickness (E.1) | 33 mm |
Plug Code | PL_2305 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 37 mm |
Pulley Type | CLUTCH |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO | S60 2.0 T | [B5204T8] | 05.2012-12.2015 |
VOLVO | V40 2.0 D3 | [D5204T6] | 03.2012-03.2015 |
VOLVO | V40 2.0 D3 | [D5204T6] | 09.2013-12.2015 |
VOLVO | V40 2.0 D3 Cross Country | [D5204T6] | 09.2013-12.2015 |
VOLVO | V40 2.0 D4 | [D5204T4] | 03.2012-12.2014 |
VOLVO | V40 2.0 D4 | [D5204T4] | 09.2013-12.2014 |
VOLVO | V40 2.0 D4 Cross Country | [D5204T4] | 09.2013-12.2014 |
VOLVO | V40 2.0 T4 | [B5204T8] | 07.2013-12.2015 |
VOLVO | V40 2.0 T4 AWD Cross Country | [B5204T8] | 07.2013-12.2015 |
VOLVO | V40 2.0 T4 Cross Country | [B5204T8] | 10.2013-12.2015 |
VOLVO | V40 2.0 T5 | [B5204T9] | 03.2013-12.2015 |
VOLVO | V40 2.0 T5 AWD Cross Country | [B5204T9] | 03.2013-12.2015 |
VOLVO | V40 2.0 T5 Cross Country | [B5204T9] | 02.2013-12.2015 |
VOLVO | V40 2.5 T5 | [B5254T12] | 12.2012-12.2014 |
VOLVO | V40 2.5 T5 AWD Cross Country | [B5254T12] | 10.2012-12.2016 |
VOLVO | V60 2.0 T | [B5204T8] | 01.2014-07.2018 |
Reference Information
32711053 554620RIB WOOALT10777 PRAE827 ALTE827 LRA03801 20894N ALT10777 209622 125711023 2010114ABN ALT12A410A 28-6911 815.545.175.280 LRA3801 DRA1169 442659 0125711023 4347 CAL10A41AS 36000613 SEG0125711053 ALB3613 UD101768A CAL10A41GS 89215955 BOS0125711053 125711053 A12BH1098AS 443411 31288880 815.545.175.010 815.545.175.210 2010A41.1 A12BH1098 815.545.175.014 2010114AOE 0125711053 815.545.175.215 2010A41.0Add Your Number
