Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 6 qty |
Length (L.1) | 172 mm |
Mount Inside Length or Pad Mount C-C (C) | 65 mm |
Outside Diameter (O.D.1) | 65 mm |
Plug Code | PL_4100 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 38 mm |
Pulley Type | SOLID |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | L200 2.5 Di-D | [4D56(16V)] | 04.2010-12.2015 |
MITSUBISHI | L200 2.5 Di-D | [4D56-HP] | 04.2010-12.2015 |
MITSUBISHI | L200 2.5 Di-D | [4D56-HP] | 08.2007-12.2015 |
MITSUBISHI | L200 2.5 Di-D 4WD | [4D56-HP] | 04.2010-12.2015 |
MITSUBISHI | L200 2.5 Di-D 4WD | [4D56-HP] | 10.2007-12.2015 |
Reference Information
447031 A005TG0491AM A12MH0364A2 AEK3337 20137222OE MITA5TG0491 28-5949 CAL35222AS 9242 LRA3337 5535471 A5TG0491 A005TG0491 553726RI 20137222BN CGB-13120 A005TG0491ZT 2035222 CAL35222GS EAA-222347 2C306 986083630 ALT5156 1800A007 A12MH0364 002-C306 A5TG0491AM LRA03337 0986083630 ALM0491 210952A 155.584.090.130 2035222.1 J5115093 ALT31302 2506125 155.584.090.370 A5TG0491ZT 155.584.090.138 UD100916(MITSUBISHI)A DRA0908N 115477 ALC306 ALTS529 89215264 DRA0908 11415NAdd Your Number
