Specifications
| Amp | 110 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 12 mm |
| Grooves | 6 qty |
| Length (L.1) | 185 mm |
| Mount Inside Length or Pad Mount C-C (C) | 74 mm |
| Outside Diameter (O.D.1) | 55 mm |
| Pad mount thickness (E.1) | 60 mm |
| Pad mount thickness (E.2) | 60 mm |
| Pad mount thickness (E.3) | 60 mm |
| Plug Code | PL_3310 |
| Product Line | Premium Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 41 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | CX-7 2.3 AWD | [L3-VDT] | 06.2006-12.2012 |
| MAZDA | CX-7 2.3 DISi | [L3K7] | 06.2006-06.2009 |
| MAZDA | CX-7 2.3 MZR DISI Turbo AWD | [L3-VDT] | 06.2006-12.2014 |
| MAZDA | CX-7 2.3 MZR DISI Turbo AWD | [L3-VDT] | 06.2009-03.2013 |
| MAZDA | CX-7 2.3 MZR DISI Turbo AWD | [L3-VDT] | 10.2007-08.2009 |
| MAZDA | CX-7 2.5 MZR | [L5-VE] | 07.2009-03.2013 |
Reference Information
MITA3TJ1191 40487 ALM0061 90-27-3383 LRA4025 A3TJ1191 2035282 A3TJ1191AM 145.556.110.138 A003TJ1191 L33G-18-300A A003TJ1191AM 20137282OE CAL35282GS ALT5417 LRA04025 CAL35282AS A3TJ1191A ALTF901 20137282BN ALT372820 ALT372820A UD100941(MITSUBISHI)A DRA1848 A003TJ1191A L33G-18-300 PRAF901 145.556.110.130 ALT31364 27-7634 145.556.110.370 2035282.1 L33G 11330N 89215240Add Your Number
