Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 384.87 including GST
NZ$ 334.67 excluding GST
or four payments of $96.22
with
Learn More
each
A6771S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
101211-0600Specifications
| Amp | 30 A |
| Bottom Mounting Foot Width (B) | 58.50 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 154 mm |
| OEM Product | No |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 16 mm |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley Outside Diameter (O.D.2) | 86.50 mm |
| Pulley to Mount Distance (A) | 97 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Dyna 200 3.0 D | [11B] | 01.1993-12.1995 |
| TOYOTA | Dyna 300 3.7 D | [14B] | 01.1993-12.1995 |
Reference Information
| 101211-0600 | DENSO |
| 101211-0601 | DENSO |
| 101211-0860 | DENSO |
| 101211-0861 | DENSO |
| 101211-0862 | DENSO |
| 112211 | CARGO |
| 196.503.030.050 | PSH |
| 27060-58220 | TOYOTA |
| 27060-58290 | TOYOTA |
| 401428RI | KUHNER |
| 48-3785 | ELSTOCK |
| 89212717 | POWERMAX |
| 8EL737721-001 | HELLA |
| A131.497 | PSH |
| A6771S | AS-PL |
| ALN1428 | KRAUF |
| ALT30161 | WOODAUTO |
| ALTE755 | 3EFFE |
| CGB-13600 | AINDE |
| CGB-83785 | AINDE |
| F032112211 | CARGO |
| JA1428IR | HC PARTS |
| LRA02507 | LUCAS |
| LRA2507 | LUCAS |
| PRAE755 | 3EFFE |
| UD21446A | AS-PL |
Video/Publications
