Specifications
Amp | 130 A |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | 12.5 mm |
Diameter (D.4) | 12.5 mm |
Length (L.1) | 227 mm |
Mount Inside Length or Pad Mount C-C (C) | 108 mm |
Pad mount thickness (E.1) | 80 mm |
Pad mount thickness (E.2) | 80 mm |
Plug Code | PL_9104 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Type | NO PULLEY |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KENWORTH | K260 6.7 | [PX-6] | 01.2008-12.2010 |
KENWORTH | K270 6.7 | [PX-6] | 01.2012-12.2013 |
KENWORTH | K360 6.7 | [PX-6] | 01.2008-12.2009 |
KENWORTH | K370 6.7 | [PX-6] | 01.2012-12.2013 |
KENWORTH | T170 6.7 | [PX-6] | 01.2008-12.2013 |
KENWORTH | T300 6.7 | [PX-6] | 01.2007-12.2007 |
PETERBILT | 210 6.7 | [PX-6] | 01.2008-12.2013 |
PETERBILT | 220 6.7 | [PX-6] | 01.2010-12.2013 |
PETERBILT | 325 6.7 | [PX-6] | 01.2008-12.2013 |
PETERBILT | 330 6.7 | [PX-6] | 01.2008-12.2013 |
PETERBILT | 335 6.7 | [PX-6] | 01.2008-12.2010 |
PETERBILT | 335 8.3 | [PX-8] | 01.2008-12.2010 |
PETERBILT | 337 6.7 | [PX-6] | 01.2010-12.2013 |
PETERBILT | 337 8.3 | [PX-8] | 01.2010-12.2013 |
PETERBILT | 340 8.3 | [PX-8] | 01.2008-12.2010 |
PETERBILT | 348 6.7 | [PX-6] | 01.2010-12.2013 |
PETERBILT | 348 8.3 | [PX-8] | 01.2010-12.2013 |
VOLVO | VNL 15.0 | [ISX] | 01.2007-12.2013 |
Reference Information
CAL40390GS 905.001.130.030 12468N ALTF134 UD30056A 115792 555122RID 905.001.130.390 D276001013 905.001.130.260 20132093OE 101211-8390 90-29-5587 ALN8390 2040390.1Add Your Number
