Specifications
| Amp | 220 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| Outside Diameter (O.D.1) | 56 mm |
| Plug Code | PL_2306 |
| Product Line | Premium Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 31 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| PORSCHE | Macan 3.0 GTS | [MDC.NA] | 10.2015-09.2018 |
| PORSCHE | Macan 3.0 S | [MCT.MA] | 02.2014-09.2018 |
| PORSCHE | Macan 3.6 Turbo | [MCT.LA] | 02.2014-09.2018 |
Reference Information
UD819288(DENSO)A 2040A47.0 28-8594 89216859 CAL40A47AS 2013274ABN 7PP903016A 485.517.220.050 7PP903016C LRA4485 40759 7PP903016CX 7PP903016AX 104210-6890 104210-6891 LRA04485 AEG1515 DAN1480 DRA1758Add Your Number
