Specifications
Amp | 160 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 12 mm |
Diameter (D.2) | 12 mm |
Diameter (D.3) | M10x1.5 mm |
Diameter (D.4) | M10x1.5 mm |
Grooves | 8 qty |
Length (L.1) | 165 mm |
Mount Inside Length or Pad Mount C-C (C) | 67.5 mm |
Outside Diameter (O.D.1) | 60 mm |
Plug Code | PL_2804 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 46 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DODGE | Ram 2500 6.7 | [408CU.IN.L6] | 01.2013- |
DODGE | Ram 3500 6.7 | [408CU.IN.L6] | 01.2012- |
Reference Information
P04801311AE UD101943A 4801311AE 421000-0513 11583N 11583 TN421000-0513Add Your Number
