Specifications
Kilowatt | 1.8 kW |
Length (L.1) | 244 mm |
Mount Hole Center - Center (O.1) | 81 mm |
Mount Hole Center - Center (O.2) | 115 mm |
Mount Hole Center - Center (O.3) | 82 mm |
Mount Hole Diameter (C.1) | 8.5 mm |
Mount Hole Diameter (C.2) | 9.5 mm |
Mount Hole Diameter (C.3) | 9.5 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 4 mm |
Rotation | CW |
Spigot Diameter (A) | 80 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JEEP | Cherokee 2.0 CRD | [EBS] | 04.2014-08.2018 |
JEEP | Cherokee 2.0 CRD | [EBT] | 04.2014-08.2018 |
JEEP | Cherokee 2.0 CRD 4x4 | [EBS] | 04.2014-08.2018 |
JEEP | Cherokee 2.0 CRD 4x4 | [EBT] | 04.2014-08.2018 |
JEEP | Cherokee 2.2 CRD | [EBU] | 08.2015-08.2018 |
JEEP | Cherokee 2.2 CRD | [EBV] | 08.2015-08.2018 |
JEEP | Cherokee 2.2 CRD | [EBV] | 09.2018- |
JEEP | Cherokee 2.2 CRD 4x4 | [EBU] | 08.2015-08.2018 |
JEEP | Cherokee 2.2 CRD 4x4 | [EBV] | 08.2015-08.2018 |
JEEP | Cherokee 2.2 CRD 4x4 | [EBV] | 09.2018- |
JEEP | Cherokee 2.2 CRD 4x4 | [LAU61] | 08.2015-08.2018 |
JEEP | Compass 2.0 CRD 4x4 | [55263087] | 03.2017- |
JEEP | Compass 2.0 CRD 4x4 | [55263088] | 12.2016- |
JEEP | Compass 2.0 CRD 4x4 | [EBS] | 03.2017- |
JEEP | Compass 2.0 CRD 4x4 | [EBS] | 12.2016- |
JEEP | Compass 2.0 CRD 4x4 | [EBT] | 03.2017- |
Reference Information
16019-OS 53480581 0001149442 88215033 K56029626AA 830.979.113.280 MAV120410 1149442 3263 56029626AA S12BH0910 20401140OE 68437087AA 256191B 221054 830.939.113.280 12452 0001149439 0001149418 RLX29626AA 0001149419 LRS3977 6010041.1 KRLX29626AA K68437087AA 1149418 1149419 1149439 CST10041GS DRS1115 25-5139 UD102078S LRS03977Add Your Number
