Specifications
| Kilowatt | 1.7 kW |
| Length (L.1) | 235 mm |
| Mount Hole Center - Center (O.1) | 84 mm |
| Mount Hole Center - Center (O.2) | 116 mm |
| Mount Hole Center - Center (O.3) | 84 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| Mount Hole Diameter (C.3) | M8x1.25 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 3 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 25 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Ducato 110 Multijet 2.3 D | [F1AE3481G] | 05.2014- |
| FIAT | Ducato 110 Multijet 2.3 D | [F1AE3481G] | 08.2006- |
| FIAT | Ducato 120 Multijet 2.3 D | [F1AE0481D] | 07.2006- |
| FIAT | Ducato 120 Multijet 2.3 D | [F1AGL4114] | 07.2006- |
| FIAT | Ducato 120 Multijet 2.3 D 4x4 | [F1AE0481D] | 03.2010- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AE0481N] | 01.2007- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AE0481N] | 08.2006- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AE3481D] | 01.2007- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AE3481D] | 08.2006- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AGL411D] | 01.2007- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AGL411D] | 08.2006- |
| FIAT | Ducato 130 Multijet 2.3 D | [F1AGL411M] | 01.2007- |
| FIAT | Ducato 130 Multijet 2.3 D 4x4 | [F1AE0481N] | 06.2011- |
| FIAT | Ducato 130 Multijet 2.3 D 4x4 | [F1AE3481D] | 06.2011- |
| FIAT | Ducato 130 Multijet 2.3 D 4x4 | [F1AGL411D] | 06.2011- |
| FIAT | Ducato 140 Multijet 2.3 D | [F1AGL4113] | 05.2019- |
| FIAT | Ducato 150 Multijet 2.3 D | [F1AE3481E] | 06.2011- |
| FIAT | Ducato 150 Multijet 2.3 D | [F1AGL411A] | 04.2015- |
| FIAT | Ducato 150 Multijet 2.3 D | [F1AGL411A] | 12.2015- |
| FIAT | Ducato 150 Multijet 2.3 D | [F1AGL411C] | 04.2015- |
| FIAT | Ducato 150 Multijet 2.3 D | [F1AGL411C] | 12.2015- |
| FIAT | Ducato 150 Multijet 2.3 D 4x4 | [F1AGL411A] | 04.2015- |
| FIAT | Ducato 150 Multijet 2.3 D 4x4 | [F1AGL411C] | 04.2015- |
| FIAT | Ducato 180 Multijet 2.3 D | [F1AGL4111] | 12.2015- |
| FIAT | Ducato 180 Multijet 2.3 D | [F1AGL411B] | 12.2015- |
Reference Information
500.590.093.010 CGB-55413 1115116 1115117 SEG0001115117 0001115116 0001115117 25-5413 0001115122 0001115123 71797401 1390671080 1115123 6.7112.1 LRS04553 256234 1115122 500.590.093.280 9879 52110466 LRS4553 71798124 K1390671080Add Your Number
