Specifications
Kilowatt | 2 kW |
Length (L.1) | 253 mm |
Mount Hole Center - Center (O.1) | 108 mm |
Mount Hole Diameter (C.1) | 13 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 32 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Accord 2.2 i-CTDi | [N22A1] | 01.2004-05.2008 |
HONDA | Accord 2.2 i-CTDi Tourer | [N22A1] | 01.2004-05.2008 |
HONDA | CR-V 2.2 CTDi | [N22A2] | 02.2005-09.2006 |
HONDA | FR-V 2.2 i CTDi | [N22A1] | 07.2005- |
Reference Information
M002T85671 M002T85672 CST35252GS SS630 UD03779(BOSCH)PR 33230N ANM12304X STR71239 LRS02230 25-3402 MHG023 120.551.092.225 WOOSTR71239 MHG020 101427 101427M 120.551.092.130 9633 336419 31200-RBD-E01 000986028040 DRS0084 31200-RBD-E010M3 12096 CST35252AS SS572 PRSS344 22.1427M M2T85672 M2T85671 6035252 8080317 J5214077 LRS2230 AEY2230 STM1427 CS1427 88213321 8EA012527-631 115327 220763 20437252OE AHG023 STR5243 220763A STRS344 6035252.1 20437252BN 986028040 22.1427Add Your Number
