Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 240 mm |
| Mount Hole Center - Center (O.1) | 118 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 29 mm |
| Rotation | CW |
| Spigot Diameter (A) | 77 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CATERPILLAR | Various Models |
Reference Information
M8T70471 M8T70473 S12MH0413 5035758 M8T70473A M8T70471A M8T70482AM CST35208GS M008T70482 31A66-00102 150.960.132.370 1958486 M008T70482AM MITM8T70482 M8T70482 31A66-10101 31A66-10100 6035208.1 S12MH0413A2 5999991254 UD14732(MITSUBISHI)S 31A6600101 20437802OE M008T70471 M008T70473 M008T70473AM M008T70471A M8T70473AM 5527659127 M8T70471AMAdd Your Number
