Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 174 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 7 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MAZDA | MX-5 1.5 | [P5-VPR] | 06.2015- |
| MAZDA | MX-5 1.5 | [P5X1] | 05.2018- |
| MAZDA | MX-5 2.0 | [PE-VPR] | 05.2018- |
| MAZDA | MX-5 2.0 | [PEX4] | 06.2015- |
| MAZDA | MX-5 2.0 | [PEX6] | 06.2015- |
| MAZDA | MX-5 2.0 | [PEXF] | 05.2018- |
| MAZDA | MX-5 RF 1.5 | [P5X1] | 05.2018- |
| MAZDA | MX-5 RF 1.5 | [P5Z1] | 08.2017- |
| MAZDA | MX-5 RF 2.0 | [PEX6] | 12.2016- |
| MAZDA | MX-5 RF 2.0 | [PEXF] | 05.2018- |
Reference Information
STM2568 P59V M000T89581 6035330.1 UD101871S MITM0T89581 M0T89581 9809 P59D-18-400 20437033OE DRS1279 P59D M000TD1271 CST35330GS LRS04232 P59V-18-400 25-5394 140.551.112.370 LRS4232 M000T89581AM M0T89581AM M0TD1271 140.551.112.130Add Your Number
