Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 195.6 mm |
| Mount Hole Center - Center (O.1) | 109 mm |
| Mount Hole Center - Center (O.2) | 71 mm |
| Mount Hole Center - Center (O.3) | 104 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 7 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 22 mm |
| Rotation | CW |
| Spigot Diameter (A) | 68 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Adam 1.0 | [B10XFL] | 07.2014-11.2018 |
| OPEL | Adam 1.0 | [B10XFT] | 07.2014-11.2018 |
| OPEL | Adam 1.0 | [D10XFL] | 07.2014-11.2018 |
| OPEL | Adam 1.0 | [D10XFT] | 07.2014-11.2018 |
| OPEL | Astra 1.4 | [B14XE] | 06.2015-12.2022 |
| OPEL | Astra 1.4 | [B14XE] | 11.2015-12.2022 |
| OPEL | Karl 1.0 | [B10XE] | 01.2015-03.2018 |
| OPEL | Karl 1.0 | [D10XE] | 01.2018-03.2019 |
| OPEL | Karl 1.0 LPG | [B10XL] | 02.2015-03.2018 |
Reference Information
95525322 95526511 6035408 M000TD5271Z OP9050 LRS3968 AC-CBS6045 95523201 UD19741S 328082132 M0TD5271ZC SMI408A M0TD5271Z 1202392 M000TD5271 12653611 LRS03968 91-27-3584 20437804BN 95520361 10035408AV CST35408AS 1202525 12638691 M000TD5271ZC 116417 34019N 220766 AEX1242 12680618 12388 25-5130 M0TD5271 388ST21 11090409 WG2013332 ST02093Add Your Number
