Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 225 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 32 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT | Panda 1.3 Multijet 4x4 | [199A9.000] | 06.2012- |
HONDA | Accord 2.0 | [R20A3] | 03.2008- |
HONDA | Accord 2.0 | [R20A3] | 07.2008- |
HONDA | Accord 2.0 i | [R20A4] | 07.2008- |
HONDA | Civic 1.6 | [R16A1] | 09.2005- |
HONDA | Civic 1.8 | [R18A1] | 02.2006- |
HONDA | Civic 1.8 | [R18A1] | 04.2006- |
HONDA | Civic 1.8 | [R18A1] | 09.2005-09.2005 |
HONDA | Civic 1.8 | [R18A2] | 01.2006- |
HONDA | Civic 1.8 | [R18Z1] | 11.2010- |
HONDA | Civic 1.8 Flexfuel | 11.2006- | |
HONDA | Civic 2.0 | [K20Z4] | 01.2008- |
HONDA | CR-V 2.0 i-VTEC | [R20A2] | 01.2007- |
HONDA | FR-V 1.8 | [R18A1] | 01.2007- |
Reference Information
LRS2577 5040605 17957N S-80394 114389 DS4R5 DS4R7 S12DE0522A2 DS4RC UD808820(DENSO)S DS4RD 428000-3410 S12DE0522 91-29-5674 120.534.092.260 120.534.092.267 120.534.092.265 CST40367GS 22.325 S1202D 120.534.092.050 DSKEV AEY2577 STN2458 DSKEQ DSKET 20432763OE 20432763BN 88212925 STR6233 336143 25-4249 31200-RNA-J01 120.534.092.058 6040367.1 31200-RNA-003 428000-5290 DRS0639 31200-RZP-E01 16092 LRS02577 428000-5011 428000-5010 6040367 31200-RNA-A11 DSKEG STRL689 CST40367AS PRSL689 220881 428000-5280 428000-5001 428000-5000 428000-3420 DSN1391 31200-RNA-A01 101458Add Your Number
