Specifications
| Kilowatt | 1.2 kW |
| Length (L.1) | 219 mm |
| Mount Hole Center - Center (O.1) | 94 mm |
| Mount Hole Diameter (C.1) | 9 mm |
| Mount Hole Diameter (C.2) | 9 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 15 qty |
| Pinion at Rest (B) | 24 mm |
| Rotation | CW |
| Spigot Diameter (A) | 75 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CADILLAC | ATS 2.0 | 01.2013-12.2014 | |
| CADILLAC | ATS 2.5 | 01.2013-12.2015 | |
| CHEVROLET | Malibu 2.5 | 01.2014- |
Reference Information
12658432 0000986CR1819 438000-1620 STN9410 0986CR1819 0986UR1819 830.940.152.260 0000986UR1819Add Your Number
