Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 196 mm |
Mount Hole Center - Center (O.1) | 118 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 18 mm |
Rotation | CW |
Spigot Diameter (A) | 76 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Mustang 5.0 GT V8 | [MF8F] | 01.2018-12.2020 |
Reference Information
UD101821S TN438000-3980 JR3Z-11002-A JR3T-11000-AA 438000-3980 880.519.102.260 S6519SAdd Your Number
