Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 220 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | 12 mm |
| Mount Hole Diameter (C.2) | 12 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 8 qty |
| Pinion at Rest (B) | 29 mm |
| Rotation | CW |
| Spigot Diameter (A) | 82 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KUBOTA | KX057-4 | ||
| KUBOTA | KX057-4CA | ||
| KUBOTA | R065 | ||
| KUBOTA | R530CA | ||
| KUBOTA | SSV65 | ||
| KUBOTA | SSV65PC | ||
| KUBOTA | SVL65-2 | ||
| KUBOTA | SVL65-2C | ||
| KUBOTA | U48-4 | ||
| KUBOTA | U55-4 | ||
| KUBOTA | U55-4CA | ||
| KUBOTA | U55-CA |
Reference Information
690.558.082.260 S12DE0385A2 255367D CST40455AS DSN2124 CST40455GS AZD2615 WOOSTR70429 428000-6940 336135 S12DE0385 STRJ567 690.558.082.050 8941 UD810316(DENSO)S 428080-6940 11.139.282 STN1626 20432554OE 116479 6040455.1 MS1150 72555945 DENDSN2124 30579N 5040581 6040455 255367 IS9568 1J730-63010 20432554BN 1J730-63011Add Your Number
