Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
| Coil Bolt Length | 25 mm |
| Inside Diameter (I.D.1) | 29.8 mm |
| L.B+ | 25 mm |
| Length (L.1) | 85.8 mm |
| Outside Diameter (O.D.1) | 60.8 mm |
| Outside Diameter (O.D.2) | 53.7 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Reference Information
72739295 MSX1013KIT LET16.915.446 MSX1013 054.000.980.090 UD49096SS 16.915.446 SOL79215 MAHMSX1013KITVideo/Publications
11131915 AZE4683 S9274 S9364S AZE4660 AZE4674 11131237 11132205 AZF4570 11132399 11131077Add Your Number
