Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
Coil Bolt Length | 26 mm |
Inside Diameter (I.D.1) | 30 mm |
L.B+ | 26 mm |
Length (L.1) | 80 mm |
Outside Diameter (O.D.1) | 62 mm |
Outside Diameter (O.D.2) | 53.5 mm |
Unit Type | ISKRA / LETRIKA |
Voltage | 24 V |
Reference Information
UD53695SS 72739336 MAHMSX1029KIT MSX1029 SSI1232 MSX1029KIT SOL79236 16.915.740Video/Publications
11132230 11132084 AZF4137 11132093 11131524 AZF4365 11132348 AZE4229 AZE4228 AZF4338Add Your Number
