Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 301.44 including GST
NZ$ 262.12 excluding GST
or four payments of $75.36
with
Learn More
each
S2124S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 1.40 kW |
| Length (L.1) | 227 mm |
| Mount Hole Center - Center (O.1) | 88 mm |
| Mount Hole Diameter (C.1) | M8x1.25 mm |
| Mount Hole Diameter (C.2) | M8x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 32 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YAMAHA | Engine | [225ETL] | 01.1990-12.1990 |
| YAMAHA | Engine | [225ETX] | 01.1990-12.1990 |
| YAMAHA | Engine | [225H.P.] | 01.1994-12.2004 |
| YAMAHA | Engine | [225TLR] | 01.1991-12.1996 |
| YAMAHA | Engine | [225TUR] | 01.1995-12.1995 |
| YAMAHA | Engine | [225TXR] | 01.1991-12.1995 |
| YAMAHA | Engine | [250ETX] | 01.1990-12.1990 |
| YAMAHA | Engine | [250H.P.] | 01.1990-12.2004 |
| YAMAHA | Engine | [250TUR] | 01.1991-12.1995 |
| YAMAHA | Engine | [250TXR] | 01.1991-12.1995 |
| YAMAHA | Engine | [L225TUR] | 01.1995-12.1996 |
| YAMAHA | Engine | [L225TXR] | 01.1994-12.1999 |
| YAMAHA | Engine | [L250ETX] | 01.1990-12.1990 |
| YAMAHA | Engine | [L250TLR] | 01.1991-12.1991 |
| YAMAHA | Engine | [L250TUR] | 01.1992-12.1999 |
| YAMAHA | Engine | [L250TXR] | 01.1992-12.1999 |
| YAMAHA | Engine | [LF225TUR] | 01.1997-12.1998 |
| YAMAHA | Engine | [LF225TXR] | 01.1997-12.1998 |
| YAMAHA | Engine | [LX225] | 01.2000-12.2000 |
| YAMAHA | Engine | [LX225TXR] | 01.2001-12.2002 |
| YAMAHA | Engine | [LX250TR] | 01.2000-12.2000 |
| YAMAHA | Engine | [LX250TUR] | 01.2001-12.2002 |
| YAMAHA | Engine | [LX250TXR] | 01.2001-12.2002 |
| YAMAHA | Engine | [P200TLR] | 01.1991-12.1996 |
| YAMAHA | Engine | [S225TUR] | 01.1996-12.1999 |
| YAMAHA | Engine | [S225TXR] | 01.1996-12.1999 |
| YAMAHA | Engine | [S250TUR] | 01.1996-12.1997 |
| YAMAHA | Engine | [S250TXR] | 01.1996-12.1999 |
| YAMAHA | Engine | [SX225TR] | 01.2000-12.2000 |
| YAMAHA | Engine | [SX225TUR] | 01.2001-12.2002 |
| YAMAHA | Engine | [SX225TXR] | 01.2001-12.2002 |
| YAMAHA | Engine | [SX250TR] | 01.2000-12.2000 |
| YAMAHA | Engine | [SX250TUR] | 01.2001-12.2002 |
| YAMAHA | Engine | [SX250TXR] | 01.2001-12.2002 |
| YAMAHA | Engine | [V200TLR] | 01.1998-12.1999 |
| YAMAHA | Engine | [V225TLR] | 01.1998-12.1999 |
| YAMAHA | Engine | [V6EXCELL] | 01.1987-12.1989 |
| YAMAHA | Engine | [V6EXCELX] | 01.1987-12.1989 |
| YAMAHA | Engine | [VMAX-200H.P.] | 01.1998-12.2005 |
| YAMAHA | Engine | [VX200TLR] | 01.2000-12.2005 |
| YAMAHA | Engine | [VX225TLR] | 01.2000-12.2004 |
| YAMAHA | Engine | [VX250TLR] | 01.2002-12.2004 |
Reference Information
| 10020220AV | ITAB AUTOMOTIVE |
| 10439311 | ALANKO |
| 18351 | LESTER |
| 18351N | WAI / TRANSPO |
| 18351N-OE | WAI / TRANSPO |
| 20445022BN | REAL |
| 2-2506-HI | WAI / TRANSPO |
| 240-10111 | DIXIE |
| 256724 | KUHNER |
| 3117821 | HENKEL PARTS |
| 400.050.092.080 | PSH |
| 400.050.092.270 | PSH |
| 6020220.0 | SANDO |
| 61A-81800-00 | YAMAHA |
| 61A-81800-00-00 | YAMAHA |
| 61A-81800-01 | YAMAHA |
| 61A-81800-01-00 | YAMAHA |
| 61H-81800-01 | YAMAHA |
| 61H-81800-01-00 | YAMAHA |
| 69L-81800-00 | YAMAHA |
| 69L-81800-00-00 | YAMAHA |
| 71-25-18351 | WILSON |
| CST20220AS | CASCO |
| MAV222200A | SIOM |
| PRSE040 | 3EFFE |
| S114-559 | HITACHI |
| S114-559B | HITACHI |
| SHI0137 | ARROWHEAD |
| SHI220A | AUTOTEAM |
| STR72246 | WOODAUTO |
| STRE040 | 3EFFE |
| UD19213S | AS-PL |
