- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
M0TD1171Associated Numbers
M0TD1175
|
180535102 |
PSH |
|---|---|
|
255332 |
Elstock |
|
256441 |
DAS |
|
3110060R00 |
Suzuki |
|
3110068P20 |
Suzuki |
|
3110081P00 |
Suzuki |
|
3110081P00000 |
Suzuki |
|
31100M68P20 |
Suzuki |
|
335974 |
Logistik |
|
345042102 |
DRI |
|
50202788 |
RE-EX |
|
88215110 |
PowerMax |
|
911308 |
EDR |
|
9856 |
CEVAM |
|
CST35373 |
Casco |
|
CST35373GS |
Casco |
|
DRS1308 |
Remy |
|
LRS04169 |
Lucas |
|
LRS4169 |
Lucas |
|
M000TD1171 |
Mitsubishi |
|
M000TD1171AM |
Mitsubishi |
|
M000TD1171ZE |
Mitsubishi |
|
M000TD1173 |
Mitsubishi |
|
M000TD1173AM |
Mitsubishi |
|
M000TD1175 |
Mitsubishi |
|
M0TD1171 |
Mitsubishi |
|
M0TD1171AM |
Mitsubishi |
|
M0TD1171ZE |
Mitsubishi |
|
M0TD1173 |
Mitsubishi |
|
M0TD1173AM |
Mitsubishi |
|
M0TD1175 |
Mitsubishi |
|
MITM0TD1171 |
Wood Auto |
|
R5218027 |
Herth Buss |
|
S144934 |
Short code |
|
S150409 |
Short code |
|
S164505 |
Short code |
|
S5585S |
AS-PL |
|
ST02788 |
TMI |
Specifications
| Kilowatt | 1.20 kW |
| Length (L.1) | 182 mm |
| Mount Hole Center - Center (O.1) | 101 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 28 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 70 mm |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Baleno 1.0 | [K10C-T] | 02.2016- |
| SUZUKI | Ignis 1.2 | [K12C] | 10.2016- |
| SUZUKI | Ignis 1.2 AllGrip | [K12C] | 10.2016- |
| SUZUKI | Ignis 1.2 Hybrid | [K12C] | 10.2016- |
| SUZUKI | Ignis 1.2 Hybrid AllGrip | [K12C] | 10.2016- |
| SUZUKI | Swift 1.0 | [K10C-T] | 04.2017- |
| SUZUKI | Swift 1.2 | [K12C] | 04.2017- |
| SUZUKI | Swift 1.2 | [K12CS] | 04.2017- |
| SUZUKI | Swift 1.2 AllGrip | [K12C] | 04.2017- |
| SUZUKI | Swift 1.2 AllGrip | [K12CS] | 04.2017- |
| SUZUKI | Swift 1.4 Sport | [K14C] | 09.2017- |
| SUZUKI | SX4 S-Cross 1.0 | [K10C-T] | 08.2016- |
| SUZUKI | SX4 S-Cross 1.0 AllGrip | [K10C-T] | 08.2016- |
| SUZUKI | SX4 S-Cross 1.4 T | [K14C] | 08.2016- |
| SUZUKI | SX4 S-Cross 1.4 T AllGrip | [K14C] | 08.2016- |
| SUZUKI | SX4 S-Cross 1.6 | [M16A] | 08.2013- |
| SUZUKI | SX4 S-Cross 1.6 | [M16A] | 12.2013- |
| SUZUKI | SX4 S-Cross 1.6 AllGrip | [M16A] | 08.2013- |
| SUZUKI | SX4 S-Cross 1.6 AllGrip | [M16A] | 12.2013- |
| SUZUKI | Vitara 1.0 | [K10C-T] | 10.2018- |
| SUZUKI | Vitara 1.0 AllGrip | [K10C-T] | 10.2018- |
| SUZUKI | Vitara 1.4 T | [K14C] | 09.2015- |
| SUZUKI | Vitara 1.4 T AllGrip | [K14C] | 09.2015- |
| SUZUKI | Vitara 1.6 | [M16A] | 02.2015- |
| SUZUKI | Vitara 1.6 | [M16A] | 05.2015- |
| SUZUKI | Vitara 1.6 AllGrip | [M16A] | 02.2015- |
| SUZUKI | Vitara 1.6 AllGrip | [M16A] | 05.2015- |
Reference Information
| 10035373OV | ITAB AUTOMOTIVE |
| 180.535.102.130 | PSH |
| 180.535.102.370 | PSH |
| 20437373OE | REAL |
| 221172A | ERA |
| 25-5332 | ELSTOCK |
| 256441M | KUHNER |
| 31100-60R00 | SUZUKI |
| 31100-68P20 | SUZUKI |
| 31100-81P00 | SUZUKI |
| 31100M68P20 | SUZUKI |
| 31302N | WAI / TRANSPO |
| 335974 | LOGISTIK |
| 345042102 | DRI |
| 6035373.1 | SANDO |
| 88215110 | POWERMAX |
| 9856 | CEVAM |
| CST35373GS | CASCO |
| LRS04169 | LUCAS |
| LRS4169 | LUCAS |
| M000TD1171 | MITSUBISHI |
| M000TD1171AM | MITSUBISHI |
| M000TD1171ZE | MITSUBISHI |
| M000TD1173 | MITSUBISHI |
| M000TD1173AM | MITSUBISHI |
| M0TD1171 | MITSUBISHI |
| M0TD1171AM | MITSUBISHI |
| M0TD1171ZE | MITSUBISHI |
| M0TD1173 | MITSUBISHI |
| M0TD1173AM | MITSUBISHI |
| MITM0TD1171 | WOODAUTO |
| SMI373 | AUTOTEAM |
| ST02788 | TMI |
| STM2428 | KRAUF |
| UD30170S | AS-PL |
Video/Publications
