Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
PRESTOLITE
Price:
NZ$ 205.13 including GST
NZ$ 178.37 excluding GST
or four payments of $51.28
with
Learn More
each
S9558S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 0.60 kW |
| Length (L.1) | 227 mm |
| Mount Hole Center - Center (O.1) | 85 mm |
| Mount Hole Center - Center (O.2) | 72 mm |
| Mount Hole Center - Center (O.3) | 125 mm |
| Mount Hole Diameter (C.1) | 10 mm |
| Mount Hole Diameter (C.2) | 8 mm |
| Mount Hole Diameter (C.3) | 8.80 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 44 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Unit Type | PRESTOLITE |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| EVINRUDE | E100 1.6 | [99.6ci-100H.P.] | 01.1969-12.1979 |
| EVINRUDE | E85 1.6 | [99.6ci-85H.P.] | 01.1964-12.1979 |
| EVINRUDE | E90 1.6 | [99.6ci-90H.P.] | 01.1970-12.1977 |
| JOHNSON | 100 | [99.6ci-100H.P.] | 01.1969-12.1979 |
| JOHNSON | 85 | [99.6ci-85H.P.] | 01.1964-12.1979 |
| JOHNSON | 90 | [99.6ci-90H.P.] | 01.1970-12.1977 |
Reference Information
| 104249 | FARCOM |
| 110646 | CARGO |
| 400.604.103.510 | PSH |
| 46-2034 | PRESTOLITE |
| 46937 | PRESTOLITE |
| 5285 | LESTER |
| 5285N | WAI / TRANSPO |
| 60874 | KUHNER |
| 71-06-5285 | WILSON |
| 91-06-1917 | WILSON |
| F032110646 | CARGO |
| MGL4008 | PRESTOLITE |
| MGL4108 | PRESTOLITE |
| SPL0009 | ARROWHEAD |
| UD13715S | AS-PL |
Video/Publications
