Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
JOHNSON ELECTRIC
Price:
NZ$ 206.63 including GST
NZ$ 179.68 excluding GST
or four payments of $51.66
with
Learn More
each
S9578S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Length (L.1) | 227 mm |
| Mount Hole Center - Center (O.1) | 89 mm |
| Mount Hole Diameter (C.1) | 8.50 mm |
| Mount Hole Diameter (C.2) | 8.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| OEM Product | No |
| Pinion at Rest (B) | 38 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | JOHNSON ELECTRIC |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HUSTLER | XL Mower | 01.1997-12.2007 | |
| NEW HOLLAND | L454 | [VSG411] | 01.1991-12.1993 |
| SNORKEL | TB50 | 01.1997-12.2007 |
Reference Information
| 10438954 | ALANKO |
| 106-10102 | ROBERT'S |
| 108658 | FARCOM |
| 20513580 | PRESTOLITE |
| 2-2948 | WAI / TRANSPO |
| 246056S | KOHLER |
| 4889440 | JOHNSON ELECTRIC |
| 4889440M030SM | UNITED TECHNOLOGIES |
| 4889440MO30SM | UNITED TECHNOLOGIES |
| 560.018.102.190 | PSH |
| 5921 | LESTER |
| 5921N | WAI / TRANSPO |
| 91-09-1070 | WILSON |
| E6JL-1100-1AA | FORD |
| MS6019 | DIXIE |
| S143.549 | PSH |
| SAB0087 | ARROWHEAD |
| SM48894 | MITSUBA |
| STR88204 | WOODAUTO |
| STZ9440 | KRAUF |
| UD13678S | AS-PL |
| WOOSTR88204 | WOODAUTO |
Video/Publications
