Specifications
Length (L.1) | 162 mm |
Mount Hole Center - Center (O.1) | 52 mm |
Mount Hole Diameter (C.1) | 6.50 mm |
Mount Hole Diameter (C.2) | 7 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
OEM Product | No |
Pinion at Rest (B) | 41 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Unit Type | MITSUBA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | CRF 230 F | [223cc] | 01.2006- |
HONDA | XLR 125 | [124cc] | 01.1996-12.2003 |
HONDA | XLR 125 R | [124cc] | 01.1998-12.1999 |
Reference Information
18850 | LESTER |
18850N | WAI / TRANSPO |
31200-KBB-901 | HONDA |
31200-KW1-901 | HONDA |
31200-KW8-901 | HONDA |
464240 | TUCKER ROCKY |
GM23003 | GAUSS |
UD19052S | AS-PL |
Video/Publications
