Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBA
Price:
NZ$ 140.98 including GST
NZ$ 122.59 excluding GST
or four payments of $35.25
with
Learn More
each
S9720S
2
Specifications
| Kilowatt | 0.60 kW |
| Length (L.1) | 196 mm |
| Mount Hole Center - Center (O.1) | 22 mm |
| Mount Hole Diameter (C.1) | 6.50 mm |
| Mount Hole Diameter (C.2) | 7.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| OEM Product | No |
| Pinion at Rest (B) | 46.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | ACW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | TRX400FW Foreman 4x4 | [395cc] | 01.1995-12.2003 |
| HONDA | TRX450ES Foreman ES | [433cc] | 01.1998-12.2001 |
| HONDA | TRX450FE Foreman ES | [433cc] | 01.2002-12.2004 |
| HONDA | TRX450FM Foreman S | [433cc] | 01.2002-12.2004 |
| HONDA | TRX450S Foreman S | [433cc] | 01.1998-12.2001 |
| HONDA | TRX500FE Foreman 4x4 ES | [475cc] | 01.2005-12.2009 |
| HONDA | TRX500FM Foreman 4x4 | [475cc] | 01.2005-12.2009 |
| HONDA | TRX500FPA Rincon GPS | [475cc] | 01.2009-12.2009 |
| HONDA | TRX500FPE Foreman 4x4 | [475cc] | 01.2007-12.2009 |
| HONDA | TRX500FPM Foreman 4x4 | [475cc] | 01.2008-12.2009 |
| HONDA | TRX500TM Foreman | [475cc] | 01.2005-12.2006 |
Reference Information
| 10439256 | ALANKO |
| 107705 | FARCOM |
| 114715 | CARGO |
| 18638 | WAI / TRANSPO |
| 18638N | WAI / TRANSPO |
| 31200-HM7-003 | HONDA |
| 31200-HM7-A41 | HONDA |
| 400.585.102.190 | PSH |
| 439256 | ALANKO |
| 71-26-18609 | WILSON |
| CMA-661079 | COMLINE |
| F032114715 | CARGO |
| HN2-0014N | JUST PARTS |
| HN2-0015N | JUST PARTS |
| MS-828 | DIXIE |
| MS-828N | DIXIE |
| RS41189 | DELCO |
| S143.514 | PSH |
| SM134-49 | MITSUBA |
| SMU0048 | ARROWHEAD |
| STR75465 | WOODAUTO |
| STU0236 | KRAUF |
| UD19165S | AS-PL |
| WOOSTR75465 | WOODAUTO |
