Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
MITSUBA
Price:
NZ$ 144.53 including GST
NZ$ 125.68 excluding GST
or four payments of $36.13
with
Learn More
each
S9726S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Kilowatt | 0.50 kW |
| Length (L.1) | 177 mm |
| Mount Hole Center - Center (O.1) | 34 mm |
| Mount Hole Diameter (C.1) | 6.50 mm |
| Mount Hole Diameter (C.2) | 6.50 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 45 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | MITSUBA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ARCTIC CAT | 1000 GT | [951cc] | 01.2012-12.2012 |
| ARCTIC CAT | 1000 LTD | [951cc] | 01.2011-12.2011 |
| ARCTIC CAT | 1000 Mud Pro | [951cc] | 01.2010-12.2013 |
| ARCTIC CAT | 1000 TRV | [951cc] | 01.2009-12.2011 |
| ARCTIC CAT | 1000 TRV Cruiser | [951cc] | 01.2009-12.2011 |
| ARCTIC CAT | 1000 TRV GT | [951cc] | 01.2012-12.2012 |
| ARCTIC CAT | 1000 TRV LTD | [951cc] | 01.2013-12.2013 |
| ARCTIC CAT | 1000 XT | [951cc] | 01.2013-12.2013 |
| ARCTIC CAT | Prowler 1000 XTZ | [951cc] | 01.2008-12.2013 |
| ARCTIC CAT | Thundercat | [951cc] | 01.2010-12.2010 |
| ARCTIC CAT | Thundercat H2 | [951cc] | 01.2010-12.2010 |
Reference Information
| 0825-015 | ARCTCO |
| 0825-025 | ARCTCO |
| 106-10411 | ROBERT'S |
| 19879 | LESTER |
| 19879N | WAI / TRANSPO |
| 242-06156 | DIXIE |
| 400.555.092.190 | PSH |
| S9726S | AS-PL |
| SM-6412V | MITSUBA |
| SMU0509 | ARROWHEAD |
| UD19151S | AS-PL |
Video/Publications
