Price:
NZ$ 446.69 including GST
NZ$ 388.43 excluding GST
or four payments of $111.67
with
Learn More
each
A01002S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | 11 mm |
| Length (L.1) | 253 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81 mm |
| Plug Code | PL_2504 |
| Pulley Grooves | 2 qty |
| Pulley Groove Width (W.1) | 12 mm |
| Pulley Outside Diameter (O.D.1) | 59 mm |
| Pulley Outside Diameter (O.D.2) | 86 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | Solid |
| Vacuum Pump | Yes |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Cabstar |
Reference Information
| 165.830.055.000 | PSH |
| 165.830.055.360 | PSH |
| 22390N | WAI / TRANSPO |
| UD102320A | AS-PL |
