Price:
NZ$ 816.93 including GST
NZ$ 710.37 excluding GST
or four payments of $204.23
with
Learn More
each
A01022(SEG)
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81.50 mm |
| Plug Code | PL_9104 |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 41 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Ducato 120 2.3 D Multijet | [F1AE0481D] | 07.2006- |
| FIAT | Ducato 120 2.3 D Multijet | [F1AGL4114] | 07.2006- |
| FIAT | Ducato 140 2.3 D Multijet | [F1AGL4113] | 05.2019- |
Reference Information
| 074ST58 | STARTCAR |
| 1986A01239 | BOSCH |
| 209768A | ERA |
| 21696N | WAI / TRANSPO |
| 2183561502 | DRI |
| 28-8690 | ELSTOCK |
| 40783 | CEVAM |
| 505.927.150.010 | PSH |
| 505.927.150.280 | PSH |
| 5481FB0055542 | FRANKBERG |
| 55101375G | MEAT & DORIA |
| 556232RI | KUHNER |
| 556232RIS | KUHNER |
| 5802407293 | IVECO |
| 58074 | EAI |
| 831015012 | TRISCAN |
| A12BH1404 | SIDAT |
| A12BH1404A2 | SIDAT |
| A147.479 | PSH |
| A155.178 | PSH |
| AL04567 | TMI |
| ALB9196 | KRAUF |
| ANM100333 | ANDEL |
| AZMT-49-035-3216 | A.Z. MEISTERTEILE |
| F000BL07CU | BOSCH |
| FI8157 | SNRA |
| FT11410 | FAST |
| G104057 | BTS TURBO |
| H55101375G | HOFFER |
| K5802407293 | IVECO |
| LRA04581 | LUCAS |
| LRA4581 | LUCAS |
| UD05226(SEG)A | AS-PL |
| WAL01413 | WALKER |
