Price:
NZ$ 894.98 including GST
NZ$ 778.24 excluding GST
or four payments of $223.75
with
Learn More
each
A01036S
No stock in NZ currently
No stock in NZ currently
Specifications
| Amp | 240 A |
| Bottom Mounting Foot Width (B) | 77.50 mm |
| Diameter (D.1) | 11.50 mm |
| Diameter (D.2) | 11.50 mm |
| Diameter (D.3) | 11.50 mm |
| Diameter (D.4) | 11.50 mm |
| Length (L.1) | 176 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 52 mm |
| Pulley to Mount Distance (A) | 88 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JEEP | Gladiator 3.0 D | [182] | 01.2021-12.2023 |
| JEEP | Wrangler 3.0 D | [182] | 01.2020-12.2023 |
Reference Information
| 0126712031 | BOSCH |
| 0126712032 | BOSCH |
| 10148 | DIXIE |
| 12902 | LESTER |
| 12902N | WAI / TRANSPO |
| 68292740AB | CHRYSLER |
| 90-15-6735 | WILSON |
| UD102658A | AS-PL |
View your shopping basket or Browse other items in Alternators.
