Price:
NZ$ 612.97 including GST
NZ$ 533.02 excluding GST
or four payments of $153.24
with
Learn More
each
A01046S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 140 A |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 156 mm |
| Mount Inside Length or Pad Mount C-C (C) | 49 mm |
| Pad mount thickness (E.1) | 58 mm |
| Pad mount thickness (E.2) | 82 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 49.50 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | 500X 1.6 | [55263842] | 11.2014-09.2020 |
| JEEP | Renegade 1.6 | [55263842] | 07.2014-09.2018 |
| JEEP | Renegade 1.6 | [EJH] | 07.2014-09.2018 |
Reference Information
| 066ST58 | STARTCAR |
| 115636 | FARCOM |
| 20010047OV | ITAB AUTOMOTIVE |
| 2010047.1 | SANDO |
| 20101740OE | REAL |
| 2010196AOE | REAL |
| 2010A69.1 | SANDO |
| 2183591402 | DRI |
| 22151N | WAI / TRANSPO |
| 28-8729 | ELSTOCK |
| 28-8729CT | AINDE |
| 40813 | CEVAM |
| 505.917.140.010 | PSH |
| 505.917.140.280 | PSH |
| 51943779 | FIAT |
| 556369RI | KUHNER |
| 556369RIB | KUHNER |
| 556369RIS | KUHNER |
| 58066 | EAI |
| 71796440 | FIAT |
| 71796443 | FIAT |
| 89214443 | POWERMAX |
| 9091360 | FRIESEN |
| A133.467 | PSH |
| A146.487 | PSH |
| AL04614 | TMI |
| ALT120470 | SIOM |
| ALT12A690 | SIOM |
| ALTJ282 | 3EFFE |
| ANM100504 | ANDEL |
| BREF032F000BL07BG | CARWOOD GROUP |
| CAL10047GS | CASCO |
| CAL10A69GS | CASCO |
| F000BL07BG | BOSCH |
| F000BL07BH | BOSCH |
| F000BL07BH-R | BOSCH |
| FI8149 | SNRA |
| G104052 | BTS TURBO |
| LRA04620 | LUCAS |
| LRA4620 | LUCAS |
| UD103084A | AS-PL |
| WAL01873 | WALKER |
| WAL01873 | WALKER |
