Price:
NZ$ 541.81 including GST
NZ$ 471.14 excluding GST
or four payments of $135.45
with
Learn More
each
A01047S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 110 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 182 mm |
| Mount Inside Length or Pad Mount C-C (C) | 80.50 mm |
| Plug Code | PL_2300 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 49.50 mm |
| Pulley to Mount Distance (A) | 44 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HATZ | Engine | [3H50T] | |
| HATZ | Engine | [3H50TI] | |
| HATZ | Engine | [3H50TIC] | |
| HATZ | Engine | [3H50TICD] | |
| HATZ | Engine | [4H50TI] | |
| HATZ | Engine | [4H50TIC] | |
| HATZ | Engine | [4H50TICD] | |
| HATZ | Engine | [4H50TIC-DPF] |
Reference Information
| 115420 | FARCOM |
| 20010061OV | ITAB AUTOMOTIVE |
| 2010061.1 | SANDO |
| 20101160OE | REAL |
| 21862N | WAI / TRANSPO |
| 50624500 | HATZ |
| 55101349G | MEAT & DORIA |
| 556493RI | KUHNER |
| 556641RI | KUHNER |
| 556641RIS | KUHNER |
| 735.501.110.010 | PSH |
| 735.501.110.280 | PSH |
| A12BH1354 | SIDAT |
| ALT120610 | SIOM |
| CAL10061GS | CASCO |
| F000BL0688 | BOSCH |
| F000BL06JF | BOSCH |
| F000BL0761 | BOSCH |
| F000BL0762 | BOSCH |
| G104034 | BTS TURBO |
| HAT50624500 | WOODAUTO |
| UD103080A | AS-PL |
