Price:
NZ$ 448.68 including GST
NZ$ 390.16 excluding GST
or four payments of $112.17
with
Learn More
each
A01050S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 110 A |
| Bottom Mounting Foot Width (B) | 50.50 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Length (L.1) | 186 mm |
| Plug Code | PL_4306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 71 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Avalanche 8.1 V8 | 01.2005-12.2005 | |
| CHEVROLET | C/K/R/V Series 6.0 V8 | 01.2005-12.2006 | |
| CHEVROLET | C/K/R/V Series 6.6 V8 D | 01.2006-12.2006 | |
| CHEVROLET | C/K/R/V Series 8.1 V8 | 01.2006-12.2006 | |
| CHEVROLET | Express 4.3 V6 | 01.2006-12.2007 | |
| CHEVROLET | Express 5.3 V8 | 01.2006-12.2006 | |
| CHEVROLET | Express 6.0 V8 | 01.2006-12.2006 | |
| CHEVROLET | Suburban 8.1 V8 | 01.2006-12.2006 | |
| GMC | C/K/R/V Series 6.0 V8 | 01.2005-12.2006 | |
| GMC | C/K/R/V Series 6.6 V8 D | 01.2006-12.2006 | |
| GMC | C/K/R/V Series 8.1 V8 | 01.2006-12.2006 | |
| GMC | Savana 4.3 V6 | 01.2006-12.2007 | |
| GMC | Savana 4.8 V8 | 01.2006-12.2006 | |
| GMC | Savana 5.3 V8 | 01.2006-12.2006 | |
| GMC | Savana 6.0 V8 | 01.2006-12.2006 | |
| GMC | Yukon XL 8.1 V8 | 01.2006-12.2006 |
Reference Information
| 0124325121 | BOSCH |
| 0124325133 | BOSCH |
| 0124325152 | BOSCH |
| 0124325153 | BOSCH |
| 0124325154 | BOSCH |
| 0124325164 | BOSCH |
| 0986UR0673 | BOSCH |
| 11076 | BOSCH |
| 11076N | WAI / TRANSPO |
| 11076R | WAI / TRANSPO |
| 15124532 | GM |
| 15200267 | GM |
| 15219565 | GM |
| 15222341 | GM |
| 15222342 | GM |
| 220-30326NOE | ROBERT'S |
| 835.588.105.280 | PSH |
| 90-15-6432 | WILSON |
| 90-15-6432N | WILSON |
| 94665137 | CHEVROLET |
| AL8789N | BOSCH |
| AL8789X | BOSCH |
| ALB5152 | KRAUF |
| F00E100288 | BOSCH |
| UD103077A | AS-PL |
