Price:
NZ$ 412.65 including GST
NZ$ 358.83 excluding GST
or four payments of $103.16
with
Learn More
each
A0244PR
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 23 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Length (L.1) | 182 mm |
| Mount Inside Length or Pad Mount C-C (C) | 58 mm |
| Plug Code | PL_9104 |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 64 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra Classic 1.6 | [Z16XEP] | 02.2006-07.2009 |
| OPEL | Astra Classic 1.6 | [Z16XEP] | 03.2006-06.2008 |
| OPEL | Astra G 1.6 | [Z16XEP] | 02.2004-11.2004 |
| OPEL | Astra G 1.6 | [Z16XEP] | 11.2002-01.2005 |
| OPEL | Astra G 1.6 | [Z16XEP] | 12.2002-05.2004 |
| OPEL | Astra G 1.6 | [Z16XEP] | 12.2002-12.2009 |
| OPEL | Astra G 1.6 LPG | [Z16XEP] | 06.2002-07.2004 |
| OPEL | Astra G 1.6 LPG | [Z16XEP] | 11.2002-06.2007 |
| OPEL | Astra H 1.6 | [Z16XE1] | 03.2004-10.2010 |
| OPEL | Astra H 1.6 | [Z16XE1] | 08.2004-10.2010 |
| OPEL | Astra H 1.6 | [Z16XEP] | 02.2007-06.2010 |
| OPEL | Astra H 1.6 | [Z16XEP] | 03.2004-10.2010 |
| OPEL | Astra H 1.6 | [Z16XEP] | 08.2004-10.2010 |
| OPEL | Astra H 1.6 EcoTec | [Z16XEP] | 02.2004-11.2004 |
| OPEL | Astra H 1.6 GTC | [Z16XE1] | 03.2005-10.2010 |
| OPEL | Astra H 1.6 GTC | [Z16XEP] | 03.2005-10.2010 |
| OPEL | Astra H 1.6 TwinTop | [Z16XE1] | 09.2005-10.2010 |
| OPEL | Astra H 1.6 TwinTop | [Z16XEP] | 09.2005-10.2010 |
| OPEL | Zafira B 1.6 | [Z16XE1] | 07.2005-09.2012 |
| OPEL | Zafira B 1.6 | [Z16XEP] | 07.2005-09.2012 |
| OPEL | Zafira Family B 1.6 | [Z16XE1] | 07.2005-09.2012 |
| OPEL | Zafira Family B 1.6 | [Z16XEP] | 07.2005-09.2012 |
Reference Information
| 011-003-000860R | REMANTE |
| 0124425020 | BOSCH |
| 0124425224 | BOSCH |
| 10444242 | ALANKO |
| 12047270 | EUROTEC |
| 135.536.100.010 | PSH |
| 18000005 | OPEL |
| 209418A | ERA |
| 2281481002 | DRI |
| 28-4941CT | AINDE |
| 28-5530 | ELSTOCK |
| 301882RI | KUHNER |
| 301882RIB | KUHNER |
| 3111130 | HENKEL PARTS |
| 3111132 | HENKEL PARTS |
| 440731 | VALEO |
| 442482 | LOGISTIK |
| 443106 | VALEO |
| 4734 | CEVAM |
| 4G0657 | RIDEX |
| 548ST75 | STARTCAR |
| 55556067 | OPEL |
| 57548 | EAI |
| 6204205 | OPEL |
| 8EL011712-481 | HELLA |
| 9047270 | FRIESEN |
| 93183437 | OPEL |
| 93190146 | OPEL |
| 944390472700 | MAGNETI MARELLI |
| AC-CBA1882 | ACAUTO |
| AL02583 | TMI |
| ALT10101 | WOODAUTO |
| ALT1402 | ELECTROLOG |
| ANM49490 | ANDEL |
| ANM49490X | ANDEL |
| AZMT-49-035-1626 | A.Z. MEISTERTEILE |
| BBA2516 | BORG & BECK |
| CAR-821395 | COMLINE |
| G100469 | BTS TURBO |
| G106213 | BTS TURBO |
| IR7923 | PROTECH |
| L47270 | ATL AUTOTECHNIK |
| LRA02916 | LUCAS |
| LRA2916 | LUCAS |
| MRA47270 | MAGNETI MARELLI |
| OP8128 | SNRA |
| QRA1612 | QUINTON HAZELL |
| SKGN-0320879 | STARK |
| WG2011358 | WILMINK GROUP |
