Price:
NZ$ 1,055.50 including GST
NZ$ 917.83 excluding GST
or four payments of $263.88
with
Learn More
each
A0271(SEG)
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 140 A |
| Diameter (D.1) | 9.50 mm |
| Diameter (D.2) | 9.50 mm |
| Diameter (D.3) | 9 mm |
| Diameter (D.4) | 9 mm |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.8 TFSi | [CABA] | 01.2008-12.2015 |
| AUDI | A4 1.8 TFSi | [CABB] | 11.2007-03.2012 |
| AUDI | A4 1.8 TFSi | [CDHA] | 01.2008-12.2015 |
| AUDI | A4 1.8 TFSi | [CDHA] | 04.2008-12.2015 |
| AUDI | A4 1.8 TFSi | [CDHB] | 11.2007-03.2012 |
| AUDI | A4 1.8 TFSi Quattro | [CDHB] | 09.2008-03.2012 |
| AUDI | A4 2.0 TFSi | [CAEA] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi | [CAEB] | 06.2008-05.2013 |
| AUDI | A4 2.0 TFSi | [CDNB] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi | [CDNC] | 06.2008-05.2013 |
| AUDI | A4 2.0 TFSi | [CFKA] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi Quattro | [CAEB] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi Quattro | [CDNC] | 06.2008-12.2015 |
| AUDI | A4 2.0 TFSi Quattro | [CPMA] | 06.2008-12.2015 |
| AUDI | A4 Allroad 2.0 TFSi Quattro | [CDNC] | 04.2009-05.2016 |
| AUDI | A4 Allroad 2.0 TFSi Quattro | [CPMA] | 04.2009-05.2016 |
| AUDI | A5 1.8 TFSi | [CABD] | 10.2007-01.2017 |
| AUDI | A5 1.8 TFSi | [CDHB] | 05.2009-09.2011 |
| AUDI | A5 1.8 TFSi | [CDHB] | 09.2009-03.2012 |
| AUDI | A5 1.8 TFSi | [CJEB] | 10.2007-01.2017 |
| AUDI | A5 1.8 TFSi Sportback | [CDHB] | 11.2009-09.2011 |
| AUDI | A5 2.0 TFSi | [CAEA] | 03.2009-03.2012 |
| AUDI | A5 2.0 TFSi | [CAEB] | 03.2009-06.2014 |
| AUDI | A5 2.0 TFSi | [CDNB] | 03.2009-03.2012 |
| AUDI | A5 2.0 TFSi | [CDNB] | 11.2008-03.2012 |
| AUDI | A5 2.0 TFSi | [CDNC] | 03.2009-06.2014 |
| AUDI | A5 2.0 TFSi | [CDNC] | 06.2008-11.2013 |
| AUDI | A5 2.0 TFSi Quattro | [CAEB] | 03.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CAEB] | 06.2008-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CDNC] | 03.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CDNC] | 06.2008-01.2017 |
| AUDI | A5 2.0 TFSi Quattro | [CPMA] | 03.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro Sportback | [CAEB] | 09.2009-01.2017 |
| AUDI | A5 2.0 TFSi Quattro Sportback | [CDNC] | 09.2009-01.2017 |
| AUDI | A5 2.0 TFSi Sportback | [CDNB] | 09.2009-06.2014 |
| AUDI | A5 2.0 TFSi Sportback | [CDNC] | 09.2009-11.2013 |
| AUDI | Q5 2.0 TFSi Quattro | [CAEB] | 11.2008-09.2012 |
| AUDI | Q5 2.0 TFSi Quattro | [CDNB] | 08.2009-05.2017 |
| AUDI | Q5 2.0 TFSi Quattro | [CDNC] | 11.2008-09.2012 |
| AUDI | Q5 2.0 TFSi Quattro | [CNCB] | 08.2009-05.2017 |
| AUDI | Q5 2.0 TFSi Quattro | [CPMA] | 11.2008-09.2012 |
Reference Information
| 0124525113 | BOSCH |
| 0124525113-R | BOSCH |
| 0124525226 | BOSCH |
| 063732007010 | MAGNETI MARELLI |
| 06H903016L | VW |
| 06H903016LX | VW |
| 0986081370 | BOSCH |
| 10443629 | ALANKO |
| 113095 | FARCOM |
| 11466N | WAI / TRANSPO |
| 115367 | CARGO |
| 12090346 | EUROTEC |
| 1986A00888 | BOSCH |
| 20010378AV | ITAB AUTOMOTIVE |
| 20010378OV | ITAB AUTOMOTIVE |
| 20101873BN | REAL |
| 20101873OE | REAL |
| 2010378.0 | SANDO |
| 2010378.1 | SANDO |
| 205.545.140.010 | PSH |
| 205.545.140.014 | PSH |
| 205.545.140.280 | PSH |
| 210850 | ERA |
| 210850A | ERA |
| 2113691402 | DRI |
| 28-5855 | ELSTOCK |
| 302007RI | KUHNER |
| 302007RIB | KUHNER |
| 302007RIR | KUHNER |
| 302ST75 | STARTCAR |
| 3114990 | HENKEL PARTS |
| 3114991 | HENKEL PARTS |
| 3114992 | HENKEL PARTS |
| 32081370 | HERTH+BUSS |
| 345005 | RHIAG |
| 440794 | VALEO |
| 442373 | LOGISTIK |
| 443255 | VALEO |
| 4663 | CEVAM |
| 4847945 | NK |
| 4G0890 | RIDEX |
| 57302 | EAI |
| 6H903016L | VW |
| 6H903016LX | VW |
| 89213826 | POWERMAX |
| 8EL011713-041 | HELLA |
| 8EL738212-451 | HELLA |
| 90-15-6622 | WILSON |
| 9061009 | HAJUS AUTOTEILE |
| A12BH0377 | SIDAT |
| A12BH0377AS | SIDAT |
| A131.769 | PSH |
| A146.204 | PSH |
| A-6619 | DIXIE |
| ABO378 | AUTOTEAM |
| ABO378A | AUTOTEAM |
| AC-CBA2007 | ACAUTO |
| AEK3244 | AUTOELECTRO |
| AL02882 | TMI |
| ALB2007 | KRAUF |
| ALT10620 | WOODAUTO |
| ALT123780 | SIOM |
| ALT123780A | SIOM |
| ALT1555 | ELECTROLOG |
| ALT539CP | ROLLCO |
| ALTF020 | 3EFFE |
| ALTF020B | 3EFFE |
| ANM32532X | ANDEL |
| AU8055 | SNRA |
| AZMT-49-035-1196 | A.Z. MEISTERTEILE |
| BOS0124525113 | WOODAUTO |
| CA2007IR | HC PARTS |
| CAL10378AS | CASCO |
| CAL10378GS | CASCO |
| CGB-85855 | AINDE |
| DA1422 | DELCO |
| DRA0312 | DELCO |
| F032115367 | CARGO |
| G100605 | BTS TURBO |
| G100606 | BTS TURBO |
| G101020 | BTS TURBO |
| H5510560 | HOFFER |
| IR6057 | PROTECH |
| L06H903016L | VW |
| L81990 | ATL AUTOTECHNIK |
| LRA03244 | LUCAS |
| LRA3244 | LUCAS |
| MQA2007 | MAGNETI MARELLI |
| PRAF020 | 3EFFE |
| QRA3497 | QUINTON HAZELL |
| SKGN-0321112 | STARK |
| TT12217 | TESLA |
| UD04729(SEG)A | AS-PL |
| V10-13-25113 | VEMO |
| WG2012310 | WILMINK GROUP |
| WG2012311 | WILMINK GROUP |
