Price:
NZ$ 1,004.89 including GST
NZ$ 873.82 excluding GST
or four payments of $251.22
with
Learn More
each
A0494,A0821S,AAM-N001
A0821(SEG)
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
|
0121715009 |
Bosch |
|---|---|
|
0121715009RB |
RNL |
|
0121715109 |
Bosch |
|
0125811051 |
Bosch |
|
0125811052 |
Bosch |
|
0125811052RB |
RNL |
|
0986086030 |
Bosch Exchange |
|
11346N |
WAI |
|
11346R |
WAI |
|
114756 |
HC-Cargo |
|
1986A01052 |
Bosch |
|
30644805 |
Volvo |
|
31110085 |
Volvo |
|
36000209 |
Volvo |
|
36012382 |
Volvo |
|
444281 |
Valeo |
|
6G9N10300B |
Ford |
|
6G9N10300MA |
Ford |
|
815520180 |
PSH |
|
90156592 |
Wilson |
|
AL0870N |
Bosch (USA) |
|
AL0870X |
Bosch (USA) |
|
ALT10691 |
Wood Auto |
|
BOS0125811051 |
Wood Auto |
|
DA1466 |
Delco Remy |
|
DRA0356 |
Delco Remy |
|
F00E100565 |
Bosch |
|
LR031223 |
Hitachi |
|
LRA03479 |
Lucas |
|
LRA3479 |
Lucas |
|
RNL715009 |
RNL |
|
WOOALT10691 |
Wood Auto |
Specifications
| Amp | 180 A |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Diameter (D.4) | 10.50 mm |
| Length (L.1) | 170 mm |
| Mount Inside Length or Pad Mount C-C (C) | 52 mm |
| Pad mount thickness (E.1) | 82 mm |
| Pad mount thickness (E.2) | 77 mm |
| Plug Code | PL_2305 |
| Pulley Type | No Pulley |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| VOLVO | S60 3.0 T6 AWD | [B6304T3] | 04.2014-12.2015 |
| VOLVO | S60 3.0 T6 AWD | [B6304T4] | 04.2010-12.2015 |
| VOLVO | S60 3.0 T6 AWD | [B6304T4] | 04.2014-12.2015 |
| VOLVO | S60 3.0 T AWD | [B6304T5] | 04.2014-12.2018 |
| VOLVO | S80 3.2 | [B6324S] | 03.2006-12.2010 |
| VOLVO | S80 3.2 | [B6324S5] | 01.2010-12.2014 |
| VOLVO | S80 3.2 AWD | [B6324S] | 01.2007-12.2010 |
| VOLVO | S80 3.2 AWD | [B6324S5] | 01.2010-12.2012 |
| VOLVO | S80 3.2 T6 AWD | [B6304T2] | 01.2007-12.2010 |
| VOLVO | S80 3.2 T6 AWD | [B6304T4] | 10.2010-12.2016 |
| VOLVO | V60 3.0 T6 AWD | [B6304T3] | 04.2014-12.2015 |
| VOLVO | V60 3.0 T6 AWD | [B6304T4] | 04.2014-12.2015 |
| VOLVO | V60 3.0 T6 AWD | [B6304T4] | 07.2010-12.2015 |
| VOLVO | V60 3.0 T AWD | [B6304T5] | 04.2014-05.2018 |
| VOLVO | V70 3.2 | [B6324S] | 08.2007-12.2010 |
| VOLVO | V70 3.2 | [B6324S5] | 04.2010-12.2014 |
| VOLVO | V70 3.2 AWD | [B6324S] | 04.2007-12.2010 |
| VOLVO | V70 3.2 AWD | [B6324S5] | 04.2010-12.2015 |
| VOLVO | V70 3.2 T6 AWD | [B6304T2] | 08.2007-12.2010 |
| VOLVO | V70 3.2 T6 AWD | [B6304T4] | 01.2010-12.2015 |
| VOLVO | XC60 3.2 AWD | [B6324S] | 07.2009-12.2010 |
| VOLVO | XC60 3.2 AWD | [B6324S5] | 03.2010-12.2015 |
| VOLVO | XC60 3.2 T6 AWD | [B6304T2] | 05.2008-12.2010 |
| VOLVO | XC60 3.2 T6 AWD | [B6304T3] | 04.2014-12.2015 |
| VOLVO | XC60 3.2 T6 AWD | [B6304T4] | 03.2010-02.2017 |
| VOLVO | XC60 3.2 T6 AWD | [B6304T4] | 04.2014-12.2015 |
| VOLVO | XC70 3.2 AWD | [B6324S] | 08.2007-12.2011 |
| VOLVO | XC70 3.2 AWD | [B6324S5] | 05.2010-12.2014 |
| VOLVO | XC70 3.2 T6 AWD | [B6304T2] | 01.2008-12.2016 |
| VOLVO | XC70 3.2 T6 AWD | [B6304T4] | 01.2010-04.2015 |
| VOLVO | XC70 3.2 T6 Polestar AWD | [B6304T4] | 11.2013-12.2016 |
| VOLVO | XC90 3.2 AWD | [B6324S] | 03.2006-12.2010 |
| VOLVO | XC90 3.2 AWD | [B6324S5] | 04.2010-09.2014 |
Reference Information
| 0121715109 | BOSCH |
| 0125811051 | BOSCH |
| 0125811052 | BOSCH |
| 0986086030 | BOSCH |
| 11346N | WAI / TRANSPO |
| 1986A01052 | BOSCH |
| 20010344OV | ITAB AUTOMOTIVE |
| 20101443OE | REAL |
| 2010344.1 | SANDO |
| 3125884 | HENKEL PARTS |
| 441760 | LOGISTIK |
| 443400 | VALEO |
| 444281 | VALEO |
| 5510763G | MEAT & DORIA |
| 6G9N-10300-B | FORD |
| 6G9N-10300-MA | FORD |
| 815.520.180.010 | PSH |
| 815.520.180.014 | PSH |
| 815.520.180.211 | PSH |
| 815.520.180.212 | PSH |
| 815.520.180.280 | PSH |
| 815.520.180.460 | PSH |
| 815.520.180.461 | PSH |
| A12BH1093 | SIDAT |
| A12BH1093AS | SIDAT |
| A135.503 | PSH |
| A148.343 | PSH |
| ALB3009 | KRAUF |
| ALT1344 | ELECTROLOG |
| BOS0125811051 | WOODAUTO |
| CAL10344GS | CASCO |
| DA1466 | DELCO |
| DRA0356 | DELCO |
| STX101295 | STARDAX |
| UD05000(SEG)A | AS-PL |
| WG2281280 | WILMINK GROUP |
| WG2283041 | WILMINK GROUP |
