Price:
NZ$ 429.84 including GST
NZ$ 373.77 excluding GST
or four payments of $107.46
with
Learn More
each
A1021PR
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 203 mm |
| Mount Inside Length or Pad Mount C-C (C) | 65 mm |
| Plug Code | PL_2001 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 59.50 mm |
| Pulley to Mount Distance (A) | 35 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra H 1.7 CDTi | [A17DTJ] | 02.2007- |
| OPEL | Astra H 1.7 CDTi | [A17DTR] | 02.2007- |
| OPEL | Astra H 1.7 CDTi | [Z17DTJ] | 02.2007- |
| OPEL | Astra H 1.7 CDTi | [Z17DTR] | 02.2007- |
| OPEL | Astra H 1.7 CDTi CRDi | [Z17DT] | 02.2007- |
| OPEL | Astra H 1.7 CDTi GTC | [A17DTR] | 02.2007- |
| OPEL | Corsa D 1.7 CDTi | [Z17DTR] | 07.2006- |
| OPEL | Meriva A 1.7 CDTi | [A17DTR] | 09.2006- |
| OPEL | Meriva A 1.7 CDTi | [Z17DTR] | 09.2006- |
| OPEL | Meriva B 1.7 CDTi | [A17DTC] | 06.2010- |
| OPEL | Meriva B 1.7 CDTi | [A17DTS] | 06.2010- |
| OPEL | Meriva B 1.7 CDTi Ecotec | [A17DT] | 06.2010- |
| OPEL | Zafira B 1.7 CDTi | [A17DTJ] | 01.2008- |
| OPEL | Zafira B 1.7 CDTi | [A17DTR] | 01.2008- |
| OPEL | Zafira B 1.7 CDTi | [Z17DTJ] | 01.2008- |
| VAUXHALL | Astra MK V 1.7 CDTi | [A17DTR] | 02.2007- |
| VAUXHALL | Astra MK V 1.7 CDTi | [Z17DT] | 02.2007- |
| VAUXHALL | Astra MK V 1.7 CDTi | [Z17DTR] | 02.2007- |
| VAUXHALL | Astra MK V 1.7 TD | 09.2008- | |
| VAUXHALL | Corsa Mk III 1.7 CDTi | [A17DTR] | 07.2006- |
| VAUXHALL | Meriva A 1.7 CDTi | [Z17DTR] | 08.2006- |
| VAUXHALL | Meriva MK II 1.7 CDTi | [A17DTC] | 06.2010- |
| VAUXHALL | Meriva MK II 1.7 CDTi 16V | [A17DT] | 06.2010- |
| VAUXHALL | Meriva MK II 1.7 CDTi 16V Ecotec | [A17DTS] | 10.2010- |
| VAUXHALL | Zafira MK II 1.7 CDTi | [A17DTR] | 01.2008- |
| VAUXHALL | Zafira MK II 1.7 TD | [A17DTJ] | 04.2009- |
Reference Information
| 11.2017 | CQ |
| 114512 | CARGO |
| 1204197 | OPEL |
| 1204425 | OPEL |
| 1207197 | OPEL |
| 135.562.140.030 | PSH |
| 135.562.140.390 | PSH |
| 135.562.140.460 | PSH |
| 20109311OE | REAL |
| 20460911OE | REAL |
| 2060113.0 | SANDO |
| 2060113.1 | SANDO |
| 210945 | ERA |
| 24094N | WAI / TRANSPO |
| 28-5706 | ELSTOCK |
| 302017RI | KUHNER |
| 302017RID | KUHNER |
| 442068 | LOGISTIK |
| 57110 | EAI |
| 6204275 | OPEL |
| 8400156 | DELCO |
| 8400158 | DELCO |
| 8400218 | DELCO |
| 89212301 | POWERMAX |
| 8980311155 | ISUZU |
| 8980311155 | ISUZU |
| 8980311551 | ISUZU |
| 89803115510 | ISUZU |
| 8980428730 | ISUZU |
| 89804287300 | ISUZU |
| 9090840 | FRIESEN |
| 9212301 | POWERMAX |
| 93169479 | OPEL |
| 98031155 | OPEL |
| 98042873 | OPEL |
| A12DR0206A2 | SIDAT |
| AEK3094 | AUTOELECTRO |
| AI-90138 | AINDE |
| ALT20206 | WOODAUTO |
| ALT20208 | WOODAUTO |
| ALT2054 | ELECTROLOG |
| ALT2055 | ELECTROLOG |
| ALT2170CP | ROLLCO |
| ALT40241 | WOODAUTO |
| ALTS789 | 3EFFE |
| ANM36515X | ANDEL |
| AX 1362 | STARLINE |
| CA2017IR | HC PARTS |
| CAL60113GS | CASCO |
| DR37M | DELCO |
| DRA2075 | DELCO |
| DRA2075N | DELCO |
| DRA4295 | DELCO |
| DRA4295N | DELCO |
| F032114512 | CARGO |
| LRA03094 | LUCAS |
| LRA3094 | LUCAS |
| PRAS789 | 3EFFE |
| R1530124 | OPEL |
| RNL8400158 | RNL |
| SB367 | SOVEREIGN |
| STX100442 | STARDAX |
| WOOALT20206 | WOODAUTO |
| WOOALT40241 | WOODAUTO |
