Price:
NZ$ 525.76 including GST
NZ$ 457.18 excluding GST
or four payments of $131.44
with
Learn More
each
A1122S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 50.50 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 175 mm |
| Plug Code | PL_2602 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 43.50 mm |
| Pulley Outside Diameter (O.D.2) | 69 mm |
| Pulley to Mount Distance (A) | 77 mm |
| Pulley Type | Solid |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CRUSADER | Engine 5.0 | [305ci] | 01.2002-12.2004 |
| CRUSADER | Engine 5.0 | [350ci] | 01.2002-12.2004 |
| CRUSADER | Engine 8.1 | [496ci] | 01.2001-12.2004 |
Reference Information
| 111281 | FARCOM |
| 19020608 | DELCO |
| 19020608-12B1 | DELCO |
| 2490 | CEVAM |
| 33000134 | GM |
| 553502RI | KUHNER |
| 553502RID | KUHNER |
| 70-01-8466 | WILSON |
| 8466N-1G | WAI / TRANSPO |
| 975.505.070.030 | PSH |
| A136.094 | PSH |
| ADL106 | AUTOTEAM |
| ALD0123 | KRAUF |
| ALT2206 | ELECTROLOG |
| ALT40027 | WOODAUTO |
| G102096 | BTS TURBO |
| G102097 | BTS TURBO |
| UD102420A | AS-PL |
| WOOALT40027 | WOODAUTO |
