Price:
NZ$ 904.20 including GST
NZ$ 786.26 excluding GST
or four payments of $226.05
with
Learn More
each
A3774S
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 52 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 2.0 30 TDi | [DEUC] | 05.2016-11.2019 |
| AUDI | A4 2.0 30 TDi | [DEUC] | 10.2018-10.2019 |
| AUDI | A4 2.0 35 TDi | [DEUA] | 08.2015- |
| AUDI | A4 2.0 35 TDi | [DEUA] | 10.2018-10.2019 |
| AUDI | A4 2.0 40 TDi | [DESA] | 05.2015- |
| AUDI | A4 2.0 40 TDi | [DESA] | 10.2018- |
| AUDI | A4 2.0 40 TDi | [DETA] | 05.2015- |
| AUDI | A4 2.0 40 TDi | [DETA] | 10.2018- |
| AUDI | A4 2.0 40 TDi Quattro | [DETA] | 09.2015-11.2019 |
| AUDI | A4 2.0 40 TDi Quattro | [DETA] | 10.2018-09.2020 |
| AUDI | A4 2.0 TDi | [CZHA] | 05.2015-11.2019 |
| AUDI | A4 2.0 TDi | [CZHA] | 08.2015-09.2018 |
| AUDI | A4 2.0 TDi | [DESA] | 05.2015- |
| AUDI | A4 2.0 TDi | [DESA] | 08.2015-09.2018 |
| AUDI | A4 2.0 TDi | [DETA] | 05.2015- |
| AUDI | A4 2.0 TDi | [DETA] | 08.2015-09.2018 |
| AUDI | A4 2.0 TDi | [DEUA] | 05.2015-11.2019 |
| AUDI | A4 2.0 TDi | [DEUA] | 08.2015-09.2018 |
| AUDI | A4 2.0 TDi | [DEUB] | 05.2015-11.2019 |
| AUDI | A4 2.0 TDi | [DEUB] | 08.2015-10.2019 |
| AUDI | A4 2.0 TDi | [DEUC] | 04.2016-09.2018 |
| AUDI | A4 2.0 TDi | [DEUC] | 05.2016-11.2019 |
| AUDI | A4 2.0 TDi | [DFVA] | 05.2015- |
| AUDI | A4 2.0 TDi | [DFVA] | 08.2015-09.2018 |
| AUDI | A4 2.0 TDi Quattro | [DESA] | 09.2015-11.2019 |
| AUDI | A4 2.0 TDi Quattro | [DESA] | 10.2015-09.2018 |
| AUDI | A4 2.0 TDi Quattro | [DETA] | 09.2015-11.2019 |
| AUDI | A4 2.0 TDi Quattro | [DETA] | 10.2015-09.2018 |
| AUDI | A4 2.0 TDi Quattro | [DETB] | 09.2016-09.2018 |
| AUDI | A4 2.0 TDi Quattro | [DETB] | 09.2016-11.2019 |
| AUDI | A4 2.0 TDi Quattro | [DEUA] | 09.2016-10.2019 |
| AUDI | A4 2.0 TDi Quattro | [DEUA] | 09.2016-11.2019 |
| AUDI | A4 2.0 TDi Quattro | [DFVA] | 09.2015-11.2019 |
| AUDI | A4 2.0 TDi Quattro | [DFVA] | 10.2015-09.2018 |
| AUDI | A4 Allroad 2.0 40 TDi Quattro | [DETA] | 01.2020- |
| AUDI | A4 Allroad 2.0 TDi Quattro | [DESA] | 01.2016- |
| AUDI | A4 Allroad 2.0 TDi Quattro | [DETA] | 01.2016- |
| AUDI | A4 Allroad 2.0 TDi Quattro | [DETB] | 05.2016-10.2019 |
| AUDI | A4 Allroad 2.0 TDi Quattro | [DEUA] | 11.2016-10.2019 |
| AUDI | A4 Allroad 2.0 TDi Quattro | [DEUB] | 11.2016-07.2018 |
| AUDI | A4 Allroad 2.0 TDi Quattro | [DFVA] | 01.2016- |
Reference Information
| 0125812189 | BOSCH |
| 04L903024H | VW |
| 04L903024HX | VW |
| 12090919 | EUROTEC |
| 205.595.180.000 | PSH |
| 2115801802 | DRI |
| 2115801802 | DRI |
| 21946N | WAI / TRANSPO |
| 28-8575 | ELSTOCK |
| 40748 | CEVAM |
| 439959 | VALEO |
| 439985 | VALEO |
| 440746 | VALEO |
| 556581RIV | KUHNER |
| 57910 | EAI |
| 910ST75 | STARTCAR |
| AL04341 | TMI |
| ALT01016 | ELECTROLOG |
| AU8100 | SNRA |
| EG18S022 | VALEO |
| LRA04466 | LUCAS |
| LRA4466 | LUCAS |
| UD91087A | AS-PL |
| VAL439985 | VALEO |
