Price:
NZ$ 759.09 including GST
NZ$ 660.08 excluding GST
or four payments of $189.77
with
Learn More
each
A3781S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 180 A |
| Diameter (D.1) | 9.50 mm |
| Diameter (D.2) | 9.50 mm |
| Diameter (D.3) | 9.50 mm |
| Diameter (D.4) | 9.50 mm |
| Length (L.1) | 180 mm |
| Mount Inside Length or Pad Mount C-C (C) | 55 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 64.50 mm |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | Solid |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 3.0 TFSi Quattro | [CREC] | 09.2014-09.2018 |
| AUDI | A7 3.0 TFSi Quattro Sportback | [CREC] | 05.2014-05.2018 |
Reference Information
| 06E903019B | VW |
| 06E903019BX | VW |
| 06E903019G | VW |
| 06E903019GX | VW |
| 20015A60OV | ITAB AUTOMOTIVE |
| 2015A60.1 | SANDO |
| 2017906AOE | REAL |
| 2115691802 | DRI |
| 2621146B | VALEO |
| 28-7967 | ELSTOCK |
| 305.946.180.000 | PSH |
| 305.946.180.500 | PSH |
| 439939 | VALEO |
| 555020RIV | KUHNER |
| 57971 | EAI |
| 971ST75 | STARTCAR |
| A147.872 | PSH |
| A151.339 | PSH |
| AL04231 | TMI |
| ALT00664 | ELECTROLOG |
| ALT17A600 | SIOM |
| ALV6024 | KRAUF |
| ANM100439 | ANDEL |
| AU8141 | SNRA |
| CAL15A60GS | CASCO |
| FG20S024 | VALEO |
| FG20S038 | VALEO |
| FG20S038 | VALEO |
| FGN20S024 | VALEO |
| FGN20S038 | VALEO |
| G104478 | BTS TURBO |
| LRA04358 | LUCAS |
| LRA04358 | LUCAS |
| UD102805A | AS-PL |
| VAL439939 | WOODAUTO |
