Price:
NZ$ 729.26 including GST
NZ$ 634.14 excluding GST
or four payments of $182.32
with
Learn More
each
A3801S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M10x1.25 mm |
| Length (L.1) | 172 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60.50 mm |
| Plug Code | PL_2306 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 53 mm |
| Pulley to Mount Distance (A) | 36 mm |
| Pulley Type | Clutch |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | RX 350 3.5 4WD | [2GR-FKS] | 10.2015- |
Reference Information
| 11936N | WAI / TRANSPO |
| 195.383.150.000 | PSH |
| 1986A01736 | BOSCH |
| 2622813 | VALEO |
| 27060-0P370 | TOYOTA |
| 27060-0P370A | TOYOTA |
| 90-22-5732 | WILSON |
| ALT01205 | ELECTROLOG |
| ALV3317 | KRAUF |
| BREF0321986A01736 | CARWOOD GROUP |
| FGN15S116 | VALEO |
| UD103166A | AS-PL |
