Price:
NZ$ 663.07 including GST
NZ$ 576.58 excluding GST
or four payments of $165.77
with
Learn More
each
A3804S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 130 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | M10x1.25 mm |
| Length (L.1) | 172 mm |
| Mount Inside Length or Pad Mount C-C (C) | 52 mm |
| Plug Code | PL_3307 |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 18 mm |
| Pulley Type | Clutch |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | i10 1.0 | [G3LA] | 08.2013-12.2019 |
| HYUNDAI | i10 1.0 LPG | [B3LA] | 02.2014-12.2019 |
| HYUNDAI | i10 1.0 LPG | [B3LA] | 07.2014-08.2016 |
Reference Information
| 115512 | FARCOM |
| 128ST58 | STARTCAR |
| 20032180OV | ITAB AUTOMOTIVE |
| 20193081OE | REAL |
| 2032180.1 | SANDO |
| 2243261302 | DRI |
| 255.537.130.000 | PSH |
| 255.537.130.500 | PSH |
| 2616532 | VALEO |
| 28-7560 | ELSTOCK |
| 28-7560CT | AINDE |
| 3116443 | HENKEL PARTS |
| 37300-04900 | HYUNDAI / KIA |
| 40401 | CEVAM |
| 4834006 | NK |
| 555392RIV | KUHNER |
| 58128 | EAI |
| 802-07191 | IAP QUALITY PARTS |
| 802-07191G | IAP QUALITY PARTS |
| 89216417 | POWERMAX |
| AL03511 | TMI |
| ALT341800 | SIOM |
| ANM98686 | ANDEL |
| CAL32180GS | CASCO |
| CGB-11684 | AINDE |
| G102206 | BTS TURBO |
| HY8065 | SNRA |
| IR5193 | PROTECH |
| LRA03950 | LUCAS |
| LRA3950 | LUCAS |
| UD103165A | AS-PL |
| WG2503860 | WILMINK GROUP |
