Price:
NZ$ 361.08 including GST
NZ$ 313.98 excluding GST
or four payments of $90.27
with
Learn More
each
A5040SR
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 70 A |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 9 mm |
| Length (L.1) | 168 mm |
| Mount Inside Length or Pad Mount C-C (C) | 46 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 31 mm |
| Pad mount thickness (E.3) | 31 mm |
| Plug Code | PL_4001 |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | Solid |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | CR-V 2.0 | [K20A4] | 07.2002-09.2006 |
| HONDA | CR-V 2.4 VTEC | [K24A1] | 03.2002-09.2006 |
| HONDA | FR-V 2.0 | [K20A9] | 02.2005- |
| HONDA | Stream 2.0 16V | [K20A1] | 05.2001- |
Reference Information
| 002-H433 | ASHIKA |
| 011-003-000919R | REMANTE |
| 102211-2680 | DENSO |
| 11.1728 | CQ |
| 11.1728M | CQ |
| 12060850 | EUROTEC |
| 1-2530-01MI | WAI / TRANSPO |
| 125.537.070.130 | PSH |
| 125.537.070.415 | PSH |
| 125.537.070.461 | PSH |
| 13966N | WAI / TRANSPO |
| 188135 | FEBI BILSTEIN |
| 20035204AV | ITAB AUTOMOTIVE |
| 20137402BN | REAL |
| 20137402OE | REAL |
| 203-5039 | PIC |
| 203-5039A | PIC |
| 203-5039B | PIC |
| 2035204.0 | SANDO |
| 2035204.1 | SANDO |
| 209356 | ERA |
| 209356A | ERA |
| 222142702 | DRI |
| 28-4857 | ELSTOCK |
| 2H433 | JAPKO |
| 31100-PNA-004 | HONDA |
| 31100-PNC-004 | HONDA |
| 31100-PND-004 | HONDA |
| 31100-PND-0041 | HONDA |
| 31100-PRB-003 | HONDA |
| 31100-RJJ-004 | HONDA |
| 31100-RJJ-0042 | HONDA |
| 3110509 | HENKEL PARTS |
| 401728RI | KUHNER |
| 447060 | LOGISTIK |
| 4826007 | NK |
| 5535971 | MEAT & DORIA |
| 57121 | EAI |
| 89212589 | POWERMAX |
| 8EL011712-461 | HELLA |
| 8EL738153-001 | HELLA |
| 90-27-3315 | WILSON |
| 90-27-3315N | WILSON |
| 9212589 | POWERMAX |
| 9438 | CEVAM |
| A002TB7591 | MITSUBISHI |
| A002TB7591ZE | MITSUBISHI |
| A002TB7591ZT | MITSUBISHI |
| A002TB8691 | MITSUBISHI |
| A002TC0691 | MITSUBISHI |
| A002TC0691A | MITSUBISHI |
| A002TC0691AE | MITSUBISHI |
| A002TC0691ZE | MITSUBISHI |
| A12MH0345A2 | SIDAT |
| A2TB7591 | MITSUBISHI |
| A2TB7591ZE | MITSUBISHI |
| A2TB7591ZT | MITSUBISHI |
| A2TB8691 | MITSUBISHI |
| A2TC0691 | MITSUBISHI |
| A2TC0691A | MITSUBISHI |
| A2TC0691AE | MITSUBISHI |
| A2TC0691ZE | MITSUBISHI |
| AC-JBA1728 | ACAUTO |
| AEB1728 | AUTOELECTRO |
| AG1228 | GHIBAUDI |
| AG1228RB | GHIBAUDI |
| AHGA-53 | HONDA |
| AHGA-55 | HONDA |
| AHGA61 | HONDA |
| AHGA-65 | HONDA |
| ALH433 | JAPANPARTS |
| ALM1728 | KRAUF |
| ALT2063 | ROLLCO |
| ALT31162 | WOODAUTO |
| ALT5167 | ELECTROLOG |
| ALTW105 | 3EFFE |
| AMI204A | AUTOTEAM |
| CAL35204AS | CASCO |
| CAL35204GS | CASCO |
| CGB-14276 | AINDE |
| DRA4276 | DELCO |
| G103163 | BTS TURBO |
| H5535971 | HOFFER |
| HO8025 | SNRA |
| IR6907 | PROTECH |
| JA1728IR | HC PARTS |
| L51150 | ATL AUTOTECHNIK |
| LRA02355 | LUCAS |
| LRA2355 | LUCAS |
| PRAW105 | 3EFFE |
| RE73742N | THE NEW LINE |
| SA874 | SOVEREIGN |
| STX100327 | STARDAX |
| STX100327R | STARDAX |
| WG2011303 | WILMINK GROUP |
| WG2263699 | WILMINK GROUP |
